Specifications
PVC Coated Gabion/Gabion Basket1. Fast delivery&Good quality
2.Output 8000m2 per day
3.Free sample available
4. ISO&CE&SGS
1. Introduction
PVC Coated Gabion Basket/Gabion Mattress/Gabions For Garden Decoration
PVC Coated Gabion/Gabion Baskets are rectangular cages made of hexagonal double-twisted wire mesh. They are filled with appropriately sized rock or quarry stone. The wire used is mild and tensile steel wire.
PVC Coated Gabion/Gabion Baskets are sub-divided into cells by inserting diaphragms which are mesh panels with the same characteristics as the external sides, separating from each other every 1m to give the structure strength and lead to speedy construction.
PVC Coated Gabion/Gabion Baskets, before being woven, can be coated with special PVC coating 0.5mm thick. This additional coating gives the structure full protection from corrosion in marine or heavily polluted environment.
PVC Coated Gabion/Gabion Baskets are used in many situations including the stabilization of earth movement and erosion, river control, reservoirs, canal refurbishment, landscaping and retaining walls.
Length (m) |
width (m) |
height (m) |
diaphragm |
volume |
tolerance |
2 |
1 |
0.3 |
1 |
0.6 |
Length+/-3% |
3 |
1 |
0.3 |
2 |
0.9 |
|
4 |
1 |
0.3 |
3 |
1.2 |
|
2 |
1 |
0.5 |
1 |
1 |
|
3 |
1 |
0.5 |
2 |
1.5 |
|
4 |
1 |
0.5 |
3 |
2 |
|
1 |
1 |
0.5 |
0 |
1 |
|
1.5 |
1 |
1 |
0 |
1.5 |
|
2 |
1 |
1 |
1 |
2 |
|
3 |
1 |
1 |
2 |
3 |
|
4 |
1 |
1 |
3 |
4 |
Opening (mm) |
Wire Diameter(Metal Wire) (mm) |
Wire Diameter (PVC Coated)/ Inner/Outside(mm) |
Strands |
60X80 |
φ2.0-2.8 |
φ2.0/3.0-2.5/3.5 |
3 |
80X100 |
φ2.0-3.2 |
φ2.0/3.0-2.8/3.8 |
3 |
80X120 |
φ2.0-3.2 |
φ2.0/3.0-2.8/3.8 |
3 |
100X120 |
φ2.0-3.4 |
φ2.0/3.0-2.8/3.8 |
3 |
100X150 |
φ2.0-3.4 |
φ2.0/3.0-2.8/3.8 |
3 |
120X150 |
φ2.0-4.0 |
φ2.0/3.0-3.0/4.0 |
3 |
(The production's material and size can be producted as the customoer's requirement.)
3. Features
F1. Economical. Just fill the stone into the gabions and seal it.
F2. Simple installation. No special technology needed.
F3. Weather proof under natural destroy, corrosion resistant.
F4. No collapse even under big scope of deforming.
F5. Sludge in the stones is good for plant growing. Mixed to form a integrity with the natural environment.
F6. Good permeation can prevent the damage by hydrostatic.
F7. Less transportation freight. It can be folded together for transportation and further installation.
4. Application
A1. Control and guide of water or flood
A2. Preventing of rock breaking
A3. Rock fall protection
A4. Water and soil protection
A5. Bridge protection
A6. Strengthening structure of soil
A7. Protection engineering of seaside area
A8. Port project
A9. Keep off dust wall
A10. Roadway protection
5. Our Services
S1. We can offer any sizes of gabion wire mesh, baskets or boxes according to the requirements of customers.
S2. We will reply you as soon as possible upon receving your request of your products.
S3. We can provide you with samples free of charge.
6. Packaging and loading
7. Customers and Certificates
8. Related Photos
Engineering Projects
Workshop Photos
9. About Konson
Konson Industrial Company Limited,with more than 15 years production experience, becomes one of the leading manufacturers of the gabions, mattress and gabion production line in China. We would like to offer good service and excellent products to customers wholeheartedly!
The company, with more than 100 experienced employees, has two workshops, one is for the gabion machine making, the other is for the gabion&mattress making. It has a production facility of more than 10 complete sets of gabion production line and four million square meters hexagonal wire mesh(gabion box) each year.
