Specifications
Retaining Wall Blocks1. Flood bank,Guiding bank
2. Economic & Fast delivery
3. Simple installation
4. No collapse&Durable
1. Introduction
Construction Used Zinc Coated Gabions/Gabion Wall/Gabion Retaining Wall
Retaining Wall Block is made up of several gabion boxes or mattresses which are filled with natural stones. As drainage occurs, soil particles deposit into the small voids of the natural stone, allowing the vegetation to take root.
Retaining Wall Block is a functional and attractive solution to unstable and sloped terrains. They are used to hold back hillsides of however large and help to prevent soil erosion and land slides.
Retaining Wall Blocks also creates more useful area for everything from patios, paths, and driveways, roads, parking lots, or any construction that requires a flat surface. We offer a variety of products to fit residential and commercial needs.
Sizes:
Standard size: 6x2x0.17m 6x2x0.23m 6x2x0.30m 3x2x0.17m 3x2x0.23m 3x2x0.30m
Mesh size(mm): 60x80mm,80x100mm,100x120mm,120x150mm
Wire diameter: 2.2mm/3.2mm,2.4mm/3.4mm,2mm/3.0mm
(We can manufacture as client's demand.)
2. Specification
Length(m) |
Width(m) |
Height(m) |
Mesh type(mm) |
3m |
2m |
0.15-0.20-0.25 |
80x100 |
4m |
2m |
0.15-0.20-0.25 |
80x100 |
5m |
2m |
0.15-0.20-0.25 |
80x100 |
6m |
2m |
0.15-0.20-0.25 |
80x100 |
3m |
2m |
0.17-0.23-0.30 |
60x80 |
4m |
2m |
0.17-0.23-0.30 |
60x80 |
5m |
2m |
0.17-0.23-0.30 |
60x80 |
6m |
2m |
0.17-0.23-0.30 |
60x80 |
(All sizes and dimensions are nominal. Tolerances of ± 3% of the width, length, and ±2.5 cm of the height shall be permitted.)
3. Characteritics
C1. Economical. It only needs to load a stone cage that can be sealed.
C2. Construction is simple, without special skills.
C3. A strong withstand natural damage and corrosion resistance and resistance to adverse effects of climate.
C4. Withstand large-scale deformation, and does not collapse.
C5. Cage rock crevice between the mud to plant production, with the surrounding natural environment melting together.
C6. Has good permeability to prevent static fluid from the damage caused.
C7. Save transportation costs. Can be folded up and assembly on site.
4. Applications
A1. Waterways and Channels
A2. River Crossing
A3. Landscaping Retaining Structures
A4. Marinas and Seashore Protection
A5. Bridges and Culvert Protection
A6. Rockfall Protection
5. Packing Photos
6. Customers Visiting and Certificates
7. Project Photos
8. Our services
S1. We can offer any sizes of gabion mesh, baskets or boxes according to the requirements of customers.
S2. We will reply you as soon as possible upon receving your request of your products.
S3. We can provide you with samples free of charge.
9. About Konson
Konson Industrial Company Limited, with more than 15 years production experience, becomes one of the leading manufacturers of the gabions, mattress and gabion production line in China. We would like to offer good service and excellent products to customers wholeheartedly!
Konson's workshop
