Specifications
High Quality Woven Gabion Box 2x1x11 ISO9001,CE,SGS test
2 Used exclusively for export
3 KONSON Brand
4 Fast delivery
1. Introduction
Hot Sale! High Quality Woven Gabion Box 2x1x1
Gabion boxes, uniformly partitioned, are wire made containers of various sizes. It is interconnected with other similar containers and filled with stones at the site of use to form flexible, permeable, monolithic structures such as retaining walls, sea walls, channel linings, revetments and weirs for earth retention. In order to strengthen the boxes, all the edges of structure are selvedged with wire of greater diameter.
Gabion box is divided into cells by diaphragms positioned at approximately 1m centers.
The wire is heavily zinc coated and for protection it can also be PVC coated. Stainless steel wire is also available according to customers’ special order. Gabion boxes are supplied in various sizes. 2m in length, 1m in width and 1m in height is the most popular size. The diameter of the wire used can also be varied.
2. Characterisitcs
1. Flexible. It can tolerate huge forces without breaking or cracking. It can adapt itself to some degree of movement.
2. Durable. If coated with PVC, the life of structure gets longer which is better for hydraulic works.
3. Permeable. Gabion box filled with stones provides an effective permeability throughout the structure.
4. Economical. Especially when the stones to fill the structure are close to the work area. Low maintenance is required for the construction works.
5. Strength. It can absorb the huge amount of energy and is very strong under tension generated by the nature.Well-made gabion structures can exist in perfect condition for many decades.
3. Applications
1. Coastal Protection
2. Building blocks of gravity walls
3. Reinforced structure
4. Control and guide of water or flood
5. Flood bank or guiding bank
6. Prevent rock from breaking
7. Bridge protection
8. Strengthen the structure of soil
9. Protect the engineering in seaside area
4. Specification
Gabion Box | |||
Opening (mm) |
Wire Diameter(Metal Wire) (mm) |
Wire Diameter (PVC Coated)/ Inner/Outside(mm) |
Strands |
60X80 |
f2.0-2.8 |
f2.0/3.0-2.5/3.5 |
3 |
80X100 |
f2.0-3.2 |
f2.0/3.0-2.8/3.8 |
3 |
80X120 |
f2.0-3.2 |
f2.0/3.0-2.8/3.8 |
3 |
100X120 |
f2.0-3.4 |
f2.0/3.0-2.8/3.8 |
3 |
100X150 |
f2.0-3.4 |
f2.0/3.0-2.8/3.8 |
3 |
120X150 |
f2.0-4.0 |
f2.0/3.0-3.0/4.0 |
3 |
| length (m) | width (m) | height (m) | diaphragm | volume | tolerance |
| 2 | 1 | 0.3 | 1 | 0.6 |
Length+/-3% Width+/-5% Height+/-5% |
| 3 | 1 | 0.3 | 2 | 0.9 | |
| 4 | 1 | 0.3 | 3 | 1.2 | |
| 2 | 1 | 0.5 | 1 | 1 | |
| 3 | 1 | 0.5 | 2 | 1.5 | |
| 4 | 1 | 0.5 | 3 | 2 | |
| 1 | 1 | 0.5 | 0 | 1 | |
| 1.5 | 1 | 1 | 0 | 1.5 | |
| 2 | 1 | 1 | 1 | 2 | |
| 3 | 1 | 1 | 2 | 3 | |
| 4 | 1 | 1 | 3 | 4 |
5. Loading and packing
6. Our services
1. We can offer any sizes of gabion mesh, baskets or boxes according to the requirements of customers.
2. We will reply you as soon as possible upon receving your request of your products.
3. We can provide you with samples free of charge.
7. Company Information
Konson Industrial Company Limited, with more than 15 years production experience, becomes one of the leading manufacturers of the gabions, mattress and gabion production line in China. We would like to offer good service and excellent products to customers wholeheartedly!
The company, with more than 100 experienced employees, has two workshops, one is for the gabion machine making, the other is for the gabion&mattress making. It has a production facility of more than 10 complete sets of gabion production line and four million square meters hexagonal wire mesh(gabion box) each year.
8. Customers and Certificates
9. Related Photos
