Help CenterGabion Production Line
Related Products
Specifications
gabion production line contains:1.Main netting machine
2.Wire tension device
3.Spiral coiling machine
4.Wire spools&payoff.
gabion machine production line
It is designed to make gabion mesh of various widths.
The production line contains the standard machines and the optional machines.
Range of supply
No |
Scope of Standard |
Supply |
1 |
Main netting machine |
1set |
2 |
Winding machine |
1set |
3 |
Wire tension device |
1set |
4 |
Spiral coiling machine |
1set |
No |
Scope of Optional |
Supply |
5 |
Gabion packing machine |
1set |
6 |
Wire spools |
1set |
7 |
Work platform |
1set |
8 |
Wire payoff |
1set |
9 |
Netting straightening machine |
1set |
10 |
Netting cutting machine |
1set |
11 |
Wrapped edge machine |
1set |
12 |
Selvedge cutting machine |
1set |
13 |
PVC coating line |
1set |
Specification of the Main netting machine
MODEL |
MESH SIZE |
MAX.WIRE DIA. |
MAX WIDTH |
PRODUCING RATE |
MOTOR POWER |
KS6080-2.4 |
60X80 mm |
3.0mm |
2400mm |
>4.8 m/min |
15 kw |
KS6080-3.2 |
3.5mm |
3200mm |
18.5 kw |
||
KS6080-4.0(4.3) |
3.5mm |
4300mm |
22 kw |
||
KS80100-2.4 |
80X100 mm |
3.5mm |
2400mm |
>4.9 m/min |
17 kw |
KS80100-3.2 |
3.5mm |
3200mm |
17 kw |
||
KS80100-4.0(4.3) |
4.0mm |
4300mm |
18.5 kw |
||
KS100120-2.4 |
100X120 mm |
3.5mm |
2400mm |
>4.3 m/min |
19 kw |
KS100120-3.2 |
3.5mm |
3200mm |
19 kw |
||
KS100120-4.0(4.3) |
4.0mm |
4300mm |
19 kw |
||
KS120150-2.4 |
120X150 mm |
4.0mm |
2400mm |
>4.4 m/min |
17 kw |
KS120150-3.2 |
4.0mm |
3200mm |
19 kw |
||
KS120150-4.0(4.3) |
4.0mm |
4300mm |
19 kw |
We can also manufacture the size as your request.
CE Certification
Packing information
