Specifications
wire mesh basket1.Mesh:60x80,80x100,100x120mm.etc
2.Straight twist or reverse twist.
3.Max. diameter.:5.0mm.
4.Free sample.
wire mesh basket
It is the gabion which are woven by the hexagonal mesh,
the diameter thickness depends on the mesh size,the diameter is between 2.0mm to 4.0mm
if the material is zinc coated,while the diameter will be 3.0mm to 5.0mm if the material is PVC-coated wire,the selvedge wire diameter usually is one gauge thicker than the body wire diameter.
Size:
Standard sizes: 6x2x0.17m 6x2x0.23m 6x2x0.30m 3x2x0.17m 3x2x0.23m 3x2x0.30m
Mesh size(mm):60x80mm,80x100mm,100x120mm,120x150mm
Wire diameter:2.2mm/3.2mm,2.4mm/3.4mm,2mm/3.0mm
We can manufacture as client's demand.
mesh(mm) |
wire(mm) |
wire(PVC)/inner/outside(mm) |
max width (mm) |
60X80 |
2.0-2.8 |
2.0/3.0-2.5/3.5 |
4300 |
80X100 |
2.0-3.2 |
2.0/3.0-2.8/3.8 |
4300 |
80X120 |
2.0-3.2 |
2.0/3.0-2.8/3.8 |
4300 |
100X120 |
2.0-3.4 |
2.0/3.0-2.8/3.8 |
4300 |
100X150 |
2.0-3.4 |
2.0/3.0-2.8/3.8 |
4300 |
120X150 |
2.0-4.0 |
2.0/3.0-3.0/4.0 |
4300 |
Projects:
