Specifications
1.Hot-dipped galvanized steel2.Advanced spiral thread
3.High-tech screw tip
4.Suitable for all types of soil
The solar ground station in accordance with the installation can mainly be divided into a concrete pedestal, the to pile implantable, self-respect, integrated several types.
Implantable to pile down to pile implantation fixed solar power system. Has a small footprint and terrestrial environmental adaptability, better wind pressure resistance snow pressure performance. Apply to the soil the bad environment neutral, non-corrosive ground Anchor.
Which to nail the type according to the needs of different terrestrial environment is divided into type C, Σ, spiral type. C-type and Σ-type is more suitable land formation rock less ground screw type suitable for rocky ground, common good.
Qingdao Wangbaoqiang Indusry Solar ground screw is the fast and cost effective work way to ground mounting system in all known
geologies natrual ground, as well as eco-friendly.
Engineered to penetrate the toughest soil conditions like rock, coral, limestone, and slate. Tip provides precise vertical alignment and allows ground screw to puncture soil quickly.
Corrosion resistance and provide a 25-year warranty.
Design: We can provide you with the most economical and suitable design for your project according to your requirements.
Customized products are accpetable, welcome your inquiries!
Design life for 20 years, 10 quality assurance, to provide customers with highly reliable quality assurance
| Grade | carbon steel, ISO630 Fe360A |
| Body dia. | 52mm-300mm |
| Thickness | 1.75mm-8mm |
| Body length | 550mm-3500mm |
| Surface treatment | electro-galv. or hot dipped galv. acc. to DIN EN ISO1461 |
| Adjustable dia. | 25mm/34mm/38mm/42mm/50mm/55mm |
| Packing | in steel pallet/ steel frame |
Sample Models
