Help Center2015 Full Automatic Concrete Block Making Machine
Related Products
Automatic Concrete Block Making Machine
SIEMENS PLC
Hydraulic Pressure
Vibration table
CE Certificate
Technology Parameter:
Main Machine Overall size (L×M×H mm): 6300×2000×2900
Pallet Size (L×M×H mm): 850×680×20
Molding Periodicity (differs from the different products):15-30 seconds
Machine Power:36KW
Machine Weight: ~8t
Molding bricks quantity:
Standard block 32pcs/ mold
Eight-hole block 15pcs/ mold
Hollow block 6pcs/ mold
Technology Description:
1, Perfect designing, such as, adopting the auto pallets feeding system, material conveying and laying out system, compulsive material disposing system and pressing and molding synchronously, has made the production recycling automatically with high production output and stable quality.
2, Machine, electricity, hydraulic are all combined together and controlled by PLC with the optional locking password to protect the running with safety. Main control table is with computerized operation screener (Chinese / English menu, LCD touching screen), which can materialize the parameter setting, single collecting along with the long-distance monitoring, breakdown seeking and system updating.
3, It is vibrated by the hydraulic-pressure motor with reasonable structure, reliable usage and high vibration efficiency. The compressing and vibration are organic combined to guarantee the density of the products.
4, It is widely used, which can produce standard block, hollow block, lightweight block, road surface pavers and so on.
Referenced Capacity XQY6-24: (as per day/ 10 hours )
|
Per mold |
Per day |
Solid Block(240*115*53mm) |
32pcs |
57600pcs |
Eight-hole Block(400*200*150mm) |
15pcs |
27000pcs |
Hollow Block(400*200*200mm) |
6pcs |
10800pcs |
