Help CenterMeanwell Switching Mode Power Supply S240
Related Products
-
Smps Power Supply S250US$ 1 - 100MOQ: 10 Pieces -
ac dc Single Output 350W Power Supply S350US$ 1 - 100MOQ: 10 Pieces
-
Single Output Switch Power Supply S400US$ 1 - 100MOQ: 10 Pieces
-
Single Output Industrial Power Supply SP500US$ 1 - 100MOQ: 10 Pieces
-
Single Output Switching Mode Power Supply SP600US$ 1 - 100MOQ: 10 Pieces
- 105°C Output capacitor
- High efficiency and low operation temperature
- Soft-start current can reduce the AC input impact effect
- With short-circuit and overload protection
- 100% full-load burn-in test
- Installed with EMI filter, minimum wave
|
Model Performance |
S-240-5 |
S-240-7.5 |
S-240-12 |
S-240-15 |
S-240-24 |
S-240-30 |
S-240-48 |
DC output voltage |
5V |
7.5V |
12V |
15V |
24V |
30V |
48V |
Output Voltage Tolerance (Note 2) |
± 2% |
± 2% |
± 1% |
± 1% |
± 1% |
± 1% |
± 1% |
Rated output current |
40A |
30A |
18A |
15A |
10A |
8A |
5A |
Output Current Range |
0 -40A |
0-30A |
0-18A |
0 -15A |
0 -10A |
0 -8A |
0 -5A |
Ripple and noise (Note 3) |
150mVp-p |
200mVp-p |
150mVp-p |
150mVp-p |
180mVp-p |
180mVp-p |
240mVp-p |
Into the line of stability (Note 4) |
± 0.5% |
± 0.5% |
± 0.5% |
± 0.5% |
± 0.5% |
± 0.5% |
± 1% |
Load stability (Note 5) |
± 1% |
± 1% |
± 0.5% |
± 0.5% |
± 0.5% |
± 0.5% |
± 1% |
DC output power |
200W |
225W |
216W |
225W |
240W |
240W |
240W |
Efficiency |
78% |
80% |
82% |
83% |
84% |
85% |
87% |
DC voltage adjustable range |
4.5-5.8V |
6-9V |
10-14V |
12-18V |
20-28V |
27-33V |
41-56V |
AC input voltage range |
88~132AC/176~264VAC by switch 47-63Hz |
||||||
Input current |
5A/115V 2.5A/230V |
||||||
AC inrush current |
Cold-start current 18A/115A 36A/230V |
||||||
Leakage current |
<3.5mA/240VAC |
||||||
Overload protection |
105%-135% Type: pulsing hiccup shutdown Reset: auto recovery |
||||||
