Specifications
Wind Generator,3KW
Multi protection will be taken into account in the wind controller.
more than 20 years span life.
Wind Driven Generator
Generator
Three phases permanent magnet (NdFeB) synchronous alternator
Model |
3KW |
Rated power( W) |
3000 |
Rated voltage( DCV) |
240 |
Rated voltage( ACV) |
170 |
Rated current( DCA) |
13 |
Magnetic pole count |
16 |
Slot count |
54 |
Rated speed( rpm) |
220 |
Max speed( rpm) |
275 |
Weight( kg) |
280 |
Efficiency (%) |
80 |
S tart-up moment(Nm) |
2.7 |
Blades
Model |
3000W |
Material of blades |
Glass Fiber |
Number of blades |
3 |
Diameter ( m) |
4.5 |
Area( m2) |
15.90 |
TSR |
5 |
Rotor power coefficient |
0.42 |
Off-grid Controller
Model |
3KW |
Dump loader power( W) |
5000 |
Batteries rated voltage( V) |
240 |
Float charge voltage( V) |
300 |
Overvoltage( V) |
300 |
Over charge resume voltage( V) |
280 |
Undervoltage( V) |
210 |
Under charge resume voltage( V) |
240 |
Net weight( kg) |
51 |
Free stand tower
Model |
|
3KW |
Height( m) |
- |
12 |
Sections |
- |
3 |
|
Specification of Top Section |
Height (m) |
4 |
Diameter (mm) |
325 |
|
Thickness (mm) |
6 |
|
|
Specification of Middle Section |
Height (m) |
4 |
Diameter (mm) |
480 |
|
Thickness (mm) |
8 |
|
|
Specification of Bottom Section |
Height (m) |
4 |
Diameter (mm) |
630 |
|
Thickness (mm) |
8 |
