ANON Rice Milling Unit

ANON Rice Milling Unit thumbnail-1
ANON Rice Milling Unit thumbnail-2
ANON Rice Milling Unit thumbnail-3
ANON Rice Milling Unit thumbnail-4
ANON Rice Milling Unit thumbnail-5
ANON Rice Milling Unit thumbnail-6
ANON Rice Milling Unit photo-1
ANON Rice Milling Unit photo-2
ANON Rice Milling Unit photo-3
ANON Rice Milling Unit photo-4
ANON Rice Milling Unit photo-5
ANON Rice Milling Unit photo-6
US$ 10,000 - 16,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Hubei, China
Brand Name:
Anon
Contact Supplier Request Quote Chat Now
Wuhan Anon Tech-Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
any Port of China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Hubei, China
Brand Name Anon
Model Number ANON 20-30T Rice Mill Set
Production Capacity 20-30ton per day
Voltage 380v,50hz,3phase
Power(W) 44.5kw
Dimension(L*W*H) 860*190*372cm
Certification ISO9001 CE GS
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

ANON Rice Milling Unit
plete rice mill plant
2.high quality,less broken rice
3.voltage 380v or custom

Anon complete rice milling plant

Product Description





Product description :  ANON Rice Milling Unit





Model:20-30T   ANON Rice Milling Unit





Main Technical Specifications of   ANON Rice Milling Unit

Capacity
Power
Overall dimensions
(L×W×H  mm)
20-30T/D
37.6KW
7500×1900×3720



20-30T unit machines:



S/N

Model

Capacity(t/h)

Power  (kw)

Qty(pcs/set)

1

Combined Cleaner

1.5-2.0

0.2×2

1

2

Husker

1.75-2.2

5.5

1

3

Paddy Separator

1.3-2.0

1.1-1.5

1

4

Rice Whitener

1.1-1.5

22

1

5

Rice Grader

1.0-1.5

1.1

1

6

Elevator



0.75×5

5

7

Blower-4-72No.3.6A



3

1

8

Blower-3.8#



1.1

1

9

Cyclone- 300



1

10

Control Panel for 20-30t/d Equipment



1

11

Steel Operating Platform



1

12

Accessories                                          (Including Collecting Dust System and its pipe)



1















































Features of Anon rice mill:

1.    Full automatic compelet production line, with latest technology

2.    Low noise and consumption, compact structure

3.    Easy to operate continuous operation.

4.    High output and low broken rate.

5.    Reasonable price.

6.    Professional Anon work team. Above solution is standard solution according to Chinese paddy features. Anon engineer will change solution to fit client’s local paddy charator and environment.

E.g:for Philippine, paddy is wet more than 15% humidity, engineer suggest large capacity of husker series.

Processing instructions:



Pre Cleaning

Removing all impurities and unfilled grains from raw paddy

De-stoning

Separating small stones from paddy

Husking

Removing husk from paddy

Husk Aspiration

Separating the husk from brown rice/ unhusked paddy

Paddy Separation

Separating the unhusked paddy from brown rice

Whitening

Removing all or part of the bran layer and germ from brown rice

Polishing

Improving the appearance of milled rice by removing the remaining bran particles and by polishing the exterior of milled kernel

Color Sorting (Optional)

Removing foreign materials such as colored, broken, immature and insected grains from milled rice

Length Grading

Separating small and large brokens from head rice

Blending

Mixing head rice with predetermined amount of brokens, as required by the customer

Weighing and Bagging

Preparing the milled rice for transport to the customer



Optional :



Paddy Dryer

Drying raw paddy with high moisture

Thickness Grader

Removing broken and immature grains from brown rice before whitening

Flow Scale

Flow controlling and incontinuous accumulating measure of white rice

Hammer Mill

Milling chaff into grainy materials

Rice Hull Separator

Separating paddy and broken brown rice from husk

Bran Separator

Separating broken rice from rice bran



Sample Project in Myanmar:

Company Information

 We reconmmend our customer provide your local eletric power information (e.g voltage:380v ; frequency:50hz , 3phase) and capacity of the machine required (e.g Paddy 1ton/hour or polished white rice 1ton/hour)
