Digital Solar Power Voltmeter Ammeter DC200A 75mV Shunt
US$ 4 - 6
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
YUANDE
Model Number:
5135F
Payment & Shipping
Payment Methods:
Port of Shipment:
Xi'an
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Solar Power Voltmeter Ammeter DC200A 75mV ShuntUS$ 4 - 6MOQ: 5 Pieces -
75mV Current Shunt 50A dc Current Shunt ResistorUS$ 1 - 2.5MOQ: 10 Pieces
-
Digital Solar Power Voltmeter Ammeter DC200A/DC20A/DC50A/DC100A 75mV ShuntUS$ 4 - 6MOQ: 5 Pieces
-
Digital Solar Power Ammeter DC200A/DC20A/DC50A/DC100A 75mV ShuntUS$ 4 - 6MOQ: 5 Pieces
-
75mV Current Shunt 50AUS$ 1 - 2.5MOQ: 10 Pieces
Place of Origin
Shaanxi, China
Brand Name
YUANDE
Model Number
5135F
Display Type
Digital Only
Phase
Single Phase
Measuring Energy Range
1.999V
Output Voltage
DC11-200V/AC12-260V
Operating Temperature
-10~50
Dimensions
79*43*30mm
Specifications
solar power Voltmeter AmmeterProducts have good stability, high measurement precision, strong anti-jamming capability
solar power Voltmeter Ammeter DC200A 75mV shunt
1.Operationg voltage: DC11-200V/AC12-260V
2. Working current:less than 30mA
3. Digital way:0.56'LED display
4. Dimension:79*43*30mm
5. Panel cutout size:76.5*39.2mm
6. Weight:60g
| Model: | Input signal | Display | Accuracy |
| YD-20A | 0~±DC20A/75mV | 0~±19.99 | ±0.01A |
| YD-50A | 0~±DC50A/75mV | 0~±50.0 | ±0.1A |
| YD-100A | 0~±DC100A/75mV | 0~±100.0 | ±0.1A |
| YD-200A | 0~±DC200A/75mV | 0~±199.9 | ±0.1A |
Digital panel meter adopts the latest model of A/D conversion chip and high stable benchmark IC, adopt SMT components, circuit design is reasonable.Can be applied to measure voltage, current, also can be an external sensor to measure temperature, pressure, displacement and other parameters.Appropriate for use in all kinds of digital instrument display.
Products have good stability, high measurement precision, strong anti-jamming capability.
With a standard size, easy to install
