Specifications
YB27VA DC0-100V digital Dual Voltmeter ammeterDC 4.5-30V 0-50A Dual LED Digital Volt meter Ammeter Voltage C
Specification:
1.Operating voltage: 4.5-30V
2.Accuracy:1%±1
3.LED size:0.28"
4.Range:DC voltage:DC0-100V(Decimal point move automatically)
DC current: DC5A/10A /DC50A/100A/200A (Under10A shunt inner)
5. Power Consumption :<20mA
6.Measuring speed:about >500 times/per
7.Dimension:48*29*21mm
8.Panel cutout size:45.5*26.5mm
Wire connection:
Five wires:
Power supply:
Thin wires: Red: Power+
Black: -
Signal terminal:
Three-Plug connector Com--Black
PW+---Red
In+------Yellow (Current input)
Digital dc voltage ammeter type is in the same instrument on the screen, respectively, at the same time show the dc voltage and dc current being measured.By measurement of dc voltage and dc current acoustic measurements within the instrument is completely isolated, the user can according to need in an external circuit adopts measure or other forms
