Aluminum Alloy Conductor Grips
1. Weight: 1~18kg
2. Rated Load: 7~80kN
3.Conductor size: LGJ25~70,LGJ95~120
4.Material: high strength aluminous alloy
5. Boyu Brand
The self-gripping clamps can be use to anchor and to string conductor. It is made of high strength aluminous alloy with characteristics of compact and light , in order to minimize the ratio between weight and working load. It is mainly applied to adjusting sag in erecting wire and sagging .
| Model | Conductor size (mm2) | Rated load (kN) | Max. opening (mm) | Weight (kg) | Material |
| SK-10 | 25~70 | 10 | 14 | 1.6 | Steel |
| SK-15 | 95~120 | 15 | 17 | 2.5 | Steel |
| SK-25 | 150~240 | 25 | 23 | 3.8 | Steel |
| SKL-7 | 25~70 | 7 | 14 | 1.0 | Aluminum |
| SKL-15 | 95~120 | 15 | 18 | 1.4 | Aluminum |
| SKL-25 | 150~240 | 25 | 24 | 3.0 | Aluminum |
| SKL-40 | 300~400 | 40 | 32 | 4.0 | Aluminum |
| SKL-50 | 500-630 | 50 | 36 | 6.6 | Aluminum |
| SKL-40G | 400 | 40 | 32 | 4.3 | Aluminum |
| SKL-50G | 500 | 50 | 34 | 7.0 | Aluminum |
| SKL-50GA | 630 | 50 | 36 | 7.3 | Aluminum |
| SKL-60G | 720 | 60 | 38 | 9.2 | Aluminum |
| SKL-70G | 900 | 70 | 42 | 14 | Aluminum |
| SKL-80G | 1000 | 80 | 45 | 18 | Aluminum |
| SKL-80GA | 1200 | 80 | 48 | 18 | Aluminum |
Note: "G" that it is equipped with protect hook, its test intensity up to 3 times, and not hurt conductor.
More pictures:
Quality Control:
We have the complete production equipments and professional production team to manage the whole process from production to packing shipment.All products will 100% test before delivery to ensure the quality.
Jiangsu Province Yixing Boyu Electric Power Industry Company is located in west side of the beautiful and fertile Taihu Lake.
Our company is high-tech enterprise of Jiangsu province having six patents, including two invention patents. Our company has a total area of 42800 square meters, having formed four series products:
1: Electric power construction tools
2: Nonmetallic galvanized the production equipment (Achieved high-tech products)
3: Numerical control machine
4: Low voltage no power-arc furnace compensation system
History
Founded in 1993, Yixing city power machinery factory
Established in 1997, Yixing city Boyu power machinery Co., LTD
In 2001 the company passed ISO9001 certification, and obtain the AAA certificate
In 2006 attains the Wuxi city contract trustworthiness enterprise, also achieved famous brand product in Wuxi city
In 2007 attains the high-tech enterprise of Jiangsu province, also achieved brand-name products in Jiangsu province
In 2009 reworded significant achievement in Wuxi city
In 2010 Boyu cooperated with Germany famous Caesar Company establishing the Boset brand
In 2010 achieved the national ministry of science and technology innovation in science and technology project.
To November 8, 2010, Boyu enterprise has already sell puller and tension equipment (excluding mobile ground grinding) nearly 4000 sets. Our products are sold well in Sudan, Kenya, Angola, Pakistan, Burma, India, Mexico,Germany.
Customer
Why choice Boyu ?
1.Quality, loyalty and service is our faith!
Deemed continuous improvement as our permanent pursuits.
2.We have introduced many advanced equipments and mature techniques, to meet various of customers’ requirements.
3.We can adjustment the price according to your market demand’s changes, and also can launch a series of promotional activities in a bad economic environment.
4.We will do our best to deal with the problems our customers encountered, in order to ensure our customers' satisfaction and also improve our better reputation.
5. 24-hour hot line: 86-0510-80329270. Once receive the customer’s enquiry , we will response within 24 hours.
6.Do the best Aluminum Alloy Conductor Grips Transmission Line Stringing Accessories in China.
