copper wire screened neutral concentric cable
Standards
VDE0276 part 603, CENELEC HD603 S1, IEC60502
7 cores and above to VDE0276 part 627, CENELEC HD627 S1, IEC 60502
Conductor
Class 1 solid plain copper, Class 2 stranded copper to BS EN 60228:2005 VDE0295, IEC 60228,
CENELEC HD383
Insulation
PVC (Polyvinyl Chloride) to CENELEC HD603.1
Bedding
PVC (Polyvinyl Chloride)
Concentric Conductor
Copper wires and helical copper tape
Sheath
PVC (Polyvinyl Chloride) to CENELEC HD603.1
Voltage Rating: 600/1000V
Minimum Bending Radius
Single Core: 15 x overall diameter
Multi-Core: 12 x overall diameter
Application
For use indoors, in cable ducts, outdoors and in earth for power plants, industrial plants, as well as in local power networks, if increased mechanical and electrical protection is required.
