1000kw Diesel Generator

Name: 1000kw Diesel Generator
Brand: Jichai
SKU: 118731643

US$ 70,000 - 77,700 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Jichai

Model Number:

LHDG1000

Shandong Lvhuan Power Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Jichai

Model Number LHDG1000

Output Type AC Three Phase

Speed 1500r/min

Frequency 50/60Hz

Rated Power 1000kw

Rated Voltage 400/230V

Rated Current 1820A

Specifications

1. Jichai diesel generator ISO9001,14001
2. China one most famous brand
3. reliable quality
4. excellent work efficiency

ENGINE DATA

Manufacturer	Jinan Diesel Engine Co.,Ltd
Model	G12V190ZL1
Type	Four stroke, water cooled, turbocharged and after-cooled, direct injection
Rated speed(RPM)	1500
Max. output(kW)	992
Cylinder no.	12
Cylinder arrangement	V 60°
Bore/Stroke(mm)	190/210
Total displacement(L)	71.45
Compress ratio	14:1
Intake system	Turbocharged
Governor	Mechanical
Start system	24V, Electrical start
Battery capacity	4×195Ah
Max. allowable back pressure(kPa)	3
Cooling system	Closed water cool
Coolant capacity(L)	250(high); 160(low)
Coolant temp.(°C)	75~80(high); 45(low)
Coolant flow(L/sec)	16.67
Fuel	0#,-10#;-20#;-35#
Fuel consumption(L/h)	205.2
Fuel consumption(g/kwh)	209.4
Lub. Oil	Kunglun CF-4
Oil capacity(L)	200
Oil consumption(g/kwh)	1.6
Oil temp.(°C)	80~95
Lubricating method	Pressure and splash lubrication
Max exhaust temp.(°C)	600
Intake Air flow(m³/min)	93
Exhaust flow(m³/min)	208
Air cycle flow(m³/min)	2100
Radiator dimension(W*H)(mm)	1710*2356.5
Direction of rotation	Counter-clockwise(facing to flywheel)
