Specifications
400*400mm working area with CE and FDA certificationDSP control system ,linear guide CO2 laser tube
for nonmetal material
Applicable materials
Wood, bamboo, jade, marble, organic glass, crystal,
plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials.
Applicable industries
Advertisement, arts and crafts, leather, toys,
garments, model , building upholster, computerized embroidery and clipping,
packaging and paper industry
Warranty:
12 Months for Machine
3 Months for laser tube, lens and mirror
6 Months for equipments outside, such as water pump, fan, air pump,etc.
TERMS & CONDITIONS:
1. PAYMENT TERMS: By T/T
2. DELIVERY TIME: Max. 7 -10 days after your order
3. PACKING: Wooden Case
Model |
QX-4040 |
Standard Laser power: |
40w |
Engraving Area(mm) |
400*400 |
Gross power |
1200w |
Laser type: |
CO2 |
Cutting depth: |
Acryl 0-40mm, others material(varied according to the nature) |
Engraving speed : |
Lasercut software: 0-1000mm/s
Newlydraw software: 0-500mm/s |
Cutting speed: |
0-500mm/s |
Resetting positioning accuracy: |
<0.01mm |
Maximum forming character: |
1*1mm |
Power supply: |
220V±10% 50HZ or 110V±10% 60HZ |
Software supported: |
ArtCut, PhotoShop (Conversion output) CorelDraw, AutoCAD, Lasercut (Direct output) |
Main Graphic format supported: |
PLT/DXF/BMP/AI (Direct output) |
Engraver for Curve surfaces: |
Rotary clamp is optional and used to engrave on curve surfaces |
Water Cooling: |
Yes |
Maximum Height of |
270mm/10.63in.(Up and down adjustable by motor) |
Laser tube(life hours): |
3000-4000 hours |
Certificate |
CE FDA |
Assistant Equipment: |
Water pump, Air pump , Exhaust Fan |
Spare Parts Recommend (R): |
Laser Tube ,Lens, mirror |
Options: Motorized up-down table, Rotary clamp, Water chiller, Auto focus, Honeycomb worktable | |
