Help CenterDMD/NMN Film Automatic Laminating Machine
Related Products
-
Double-face Dry-type Laminating/Composite Machine JHJ-GFJ1300NegotiableMOQ: 1 Set -
Multifunctional Automatic Mica Tape Laminating / Composite Machine JHJ- JYT1100NegotiableMOQ: 1
-
Multifunctional Automatic Mica Tape Laminating / Composite Machine JHJ- DYT1100NegotiableMOQ: 1 Set
-
Double-surface Dry Film Laminating Machine for DMN, DMD-F, DMD, NHN, NKNNegotiableMOQ: 1 Set
-
Multifunctional Automatic Electrical Insulation Mica Paper Tape Lamination MachineNegotiableMOQ: 1 Set
Specifications
Double-face Dry-type Laminating/Composite Machine is using glue to compound the PET film, non-woven polyester fabric or paper.FHJ1550 Double-surface Dry-type Laminating Machine is applicable of manufacturing various type of composite materials such as DMN, DMD-F, DMD, NHN, NKN and so on.
Features:
1, Using glue to compound the PET film, non-woven polyester fabric or paper. (Film thickness after laminating: 0.08-1.2mm)
2, The effective width of gluing the PET film, non-woven polyester fabric or paper is 800-1800mm., the machine can adopt single or double surface gluing, after drying process and coating single or double surface of the film and then rewinding.
Main technical parameters:
1, The fastest speed of the machine: 15m/min
2, The maxium diameter of unwinding: Φ600mm
3, Rewinding diameter: Φ800mm
4, Paper tube inner diameter: Φ76mm
5, Drying cabinets’s temperature control( Three stage temperature control ):
Tmax=150°C±2°C
6, Heating roller temperature control: Tmax=100°C±2°C
7,Total power: about 33KW
8,Machine’s dimension: 9800*2100*2000mm.
The main parts of the machine:
unwinding device, gluing device, drying device, coating device, rewinding device, electric control system and pneumatic device.
