Home > Electrical & Electronics > Electronic Tube & Transistor > Rectifier Diode > 1N4007 1200V Ultra Fast Silicon Rectifier Diode

1N4007 1200V Ultra Fast Silicon Rectifier Diode

1N4007 1200V Ultra Fast Silicon Rectifier Diode photo-1

1N4007 1200V Ultra Fast Silicon Rectifier Diode photo-2

US$ 0.001 - 0.001 MOQ: 1000 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

Model Number:

1N4007

Contact Supplier Request Quote Chat Now

Changzhou Trustec Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

ShangHai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name CY

Model Number 1N4007

Type Rectifier Diode

Package Type Through Hole

Max. Forward Voltage 1 V

Max. Reverse Voltage 1000 V

Max. Forward Current 1 A

Max. Reverse Current 5 μA

Specifications

1.Silicon Diode
2.ROHS & ISO9001 certification
3.Top quality & competitive price
4.Efficient export service

Related Product

Rectifier Diode 1A~10A 50V~1000V

Fast Recovery Diode 1A~10A 50V~1000V

Switching Diode

High Efficiency Diode 1A~6A 50V~1000V

Ultra Fast Diode 1A~3A 50V~1000V

Super Fast Diode 1A~8A 50V~600V

High Speed Switching Diode

High Voltage Diode 1200V~15000V

SMD Rectifier Diode 1A~3A 50V~1000V

SMD Fast Recovery Diode 1A~3A 50V~1000V

SMD Ultra Fast Diode 1A~3A 50V~1000V

SMD Schottky Diode 1A~3A 20V~100V

Schottky Diode 1A~15A 20V~100V

Zener Diode 0.5W~1W

TVS Diode 400W~5000W

Dual Schottky Diode 10A~50A 20V~60V

Bidirectional DIACS

Bridge Rectifier 1A~50A 50V~1000V

Product Description

Features

. Diffused junction

. Low Leakage

. Low forward voltage drop

. High current capability

. Easily cleaned with Freon, Alcohol, Lsopropanol and similar solvents

. The plastic material carries U/L recognition 94V-O

Mechanical Data

. Case: JEDEC DO-41 molded plastic

. Terminals: Axial leads Solderable per MIL-STD-750 Method 2026

. Polarity: Color band denotes cathode

. Weight: 0.012 ounce. 0.33grams

. Mounting position: Any

Electrical Characteristics

	Symbol	1N4001	1N4002	1N4003	1N4004	1N4005	1N4006	1N4007	1N4007*	Units
Max Reverse Voltage	Vrrm	50	100	200	400	600	800	1000	1200	V
Max RMS Voltage	Vrms	35	70	140	280	420	560	700	960	V
Max DC Blocking Voltage	Vdc	50	100	200	400	600	800	1000	1200	V
Max Forward Current	Iav	1.0								A
Peak Forward Surge Current	Ifsm	30								A
Max Forward Voltage	Vf	1.0								V
Max Reverse Current Ta=25℃ Ta=100℃	Ir	5.0 50.0								μA
Typical Junction Capacitance	Cj	15								pF
Typical Thermal Resistance	Rqja Rqjl	50 25								℃/W
Junction Temperature	Tj	-55-125								℃
Storage Temperature	Tstg	-55-150								℃

Packaging & Shipping

Tape Packing (T/B)

Package	QTY Per Tape (pcs)	Component Size (mm)	Tape Size (mm)	Box Size (mm)	Carton Size (mm)	QTY Per Carton (pcs)	Gross Weight (kg)
DO-41-1	5000	5.0	52	25580140	370280310	50000	16.00
DO-41-2	5000	5.0	52	25580145	420280310	50000	19.00
DO-41-3	5000	5.0	52	25550140	440280310	80000	15.00
DO-41-4	2500	5.0	52	2558088	420280310	37500	19.00
DO-15	2500	5.0	52	25580140	420280310	25000	19.00
DO-27	1000	9.5	52	25580145	420280310	10000	14.00
R-6	500	9.5	52	25580140	420280350	5000	14.00

Bulk Packing (B/P)

Package	QTY Per Box (pcs)	Inner Box Size (mm)	Carton Size (mm)	QTY Per Carton (pcs)	Gross Weight (kg)
DO-41-1	1000	1898121	393215250	50000	16.00
DO-41-2	2000	1898121	443215250	50000	16.00
DO-15	500	1898121	443215250	25000	13.00
DO-27	200	1898121	443215250	10000	15.00
R-6	100	1898121	443215250	5000	8.00

Shipping

Shipping Service

1. We will ship all your order within 7-15 days after the order confirmation.
2. We can Ship via your shipping account as your instruction.
3. Regarding the declared value on the package for customs clearance, we are pleased to follow your wishes, just feel free to inform us when ordering.

Our Services

1. Free Sample.

2. Contact us freely for samples and detailed characteristics, we would reply at the first time.

3. CY brand/ MIC brand/ OEM.

4. Payment Terms: 100% TT before shipment basing on FOB terms.

20% TT advanced payment, 80% TT against BL copy on C&F terms.

Company Information

Changzhou Trustec Co., Ltd

Changzhou Changyuan Electronics Co.,Ltd

Professional and leading diode manufacturer in China with ROHS and ISO9001:2008 certification.

Products: silicon diode, switching diode, high efficiency diode, trigger diode, schottky diode,

SMD diode, energy saving lamp diode and switching power supply diode.

Production capacity: 300,000,000 pieces of diodes per month.

Top quality: OEM for Good-ark electronic, Merrill lynch electronic, Star Sea electronic, Tak Cheong electronic, Panjit electronic and cooperate with Pentium electrical, NVC and Samsung electronic.

Application: Military project, Aerospace project, Solar junction box, Telecommunication, Railway, Civil products

Well-regulated workshops

Precise production and test equipment

FAQ

Q1: Do you have a test room?

Yes, we have professional staff to take various detection and life test for every batch of diodes,

and special simulation testing equipment aimed at the lighting industry.

Q2: What is your Lead Time?

For general diode and standard printing and packaging request, shipment in 3 days.

For special printing or packaging the first time, normal lead time would be 15 days.

If the order quantity is large, we hope customers place order 15 days in advance for safety.

Q3: Can customers provide logo by themselves?

We can print according to the samples provided by customers if they need special requirement,

but delivery time would be longer because of the extra producing time for printing mold and packaging material.

Q4: Why choose cooperation with us?

Monthly production capacity up to 300 million pieces and short delivery time.

Factory and products pass ISO9001:2008 certification, all products are conformed to RoHS.

Foreign trade team with 7 years of professional export experience can meet various customer requirements.

OEM for Good-ark electronic, Merrill lynch electronic, Star Sea electronic, Tak Cheong electronic, Panjit electronic and cooperate with Pentium electrical, NVC and Samsung electronic.
