Specifications
The machine is applied in the industries of pharmaceutics,chemical .food and etc.30B Dust Collecting Crushing Set
Model |
Crushing Motor(kw) |
Discharge fineness(mesh) |
WF20 |
4 |
60-120 |
WF30 |
5.5 |
60-120 |
WF40 |
7.5 |
60-120 |
|
|
|
Production Capacity(kg/h) |
Spindle speed(r/min) |
Feeding Fineness(mm) |
60-150 |
4500 |
less than 12 |
100-300 |
3800 |
less than 12 |
160-800 |
3400 |
less than 15 |
Operating principle:
By means of relative motion between movable and fixed discs,material is crushed though impact and friction of the teeth and impact among the material.well-crushed material runs to the catcher automatically by the rotarycentrifugal force.Dusts are collected through the collector box and get filtered to recycle .The machine is designed according to GMP standard and made of stainless steel .There is no dust in the air during the crushing process .It not only improves the utilization rate of the material but also reduce the company cost.Its perfermance is up to the international advanced level.
