Help Center255w Mono Solar Panel
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
JS
Model Number:
JS255M
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
245w Poly Solar Modules With 60pcs 156*156 Poly Cells With CE, TUV, UL, CSA, MCS PV CYCLENegotiableMOQ: 1 -
255w Poly Solar Modules With 60pcs 156*156 Poly Cells With CE, TUV, UL, CSA, MCS PV CYCLENegotiableMOQ: 1
-
260w Poly Solar Modules With 60pcs 156*156 Poly Cells With CE, TUV, UL, CSA, MCS PV CYCLENegotiableMOQ: 1
-
300w Poly Solar Modules With 72pcs 156*156 Poly Cells With CE, TUV, UL, CSA, MCS PV CYCLENegotiableMOQ: 1
-
285w Poly Solar Modules With 72pcs 156*156 Poly Cells With CE, TUV, UL, CSA, MCS PV CYCLENegotiableMOQ: 1
Place of Origin
Jiangsu, China
Brand Name
JS
Model Number
JS255M
Material
Monocrystalline Silicon
Size
1640mm*992mm*40mm
Number of Cells
60cells
Max. Power
255W
Specifications
Thanks for checking the following detailed specification.
Electric Characteristics(STC)
Type JS255M
Nominal Power(Pmax)[W]: 255
Voltage at Pmax(Vmp)[V]: 31
Current at Pmax(Imp)[A]: 8.23
Open Circuit Voltage(Voc)[V]: 36.9
short circuit Current(Isc)[A]: 8.94
Power Tolerance[%]: 0-3
Maximum System Voltage[V]: 1000
Module Efficiency[%]: 15.62
Specifications
Dimension A*B*C(mm): 1640*992*40
Weight(kg): 20
Cable Length(mm): 900
Type of Connector: MC4
Product Guarantee
25-year linear performance warranty
10-year warranty on materials and workmanship
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2007
Factory Size
30,000-50,000 square meters
Total Employees
51 - 100 People
