YT41 100T Small Single-Column Hydraulic Press Brake Machine
Introduction
YT41 series desktop small single-column hydraulic press, is a versatile small hydraulic machine, press-fit bushings for shaft parts and magnetic parts, you can complete imprint, set-shaped and other activities.
Pressed powder is not very strict, plastic products, mainly for mobile phones bed, engine, electrical, bearings, washers, car motors, stepper machines and other industries, especially for foreign-funded enterprises to use the assembly line.
Specification
Item |
Press Brake Machine |
Model |
Press Brake Machine -YT41-2.5T |
Type |
2.5T |
Nominal Force |
25KN |
Max. Pressure of Liquid |
4.4Mpa |
Max. Opening Height |
300mm |
Max. Slide Stroke |
160mm |
Slide Speed |
Down:42mm/s |
Return:70mm/s | |
Depth of Throat |
160mm |
Table Size |
F.B:210mm |
L.R:400mm | |
Table Height Above The Floor |
200mm |
Motor Power |
2.2KW |
Outline Dimensions |
F.B:720mm |
L.R:540mm | |
Height:1120mm | |
Total Weight |
0.28T |
Warranty |
1 year |
Certificate |
CE, ISO9001 |
MOQ |
1 Set Press Brake Machine |
Delivery Time |
15-30days For Press Brake Machine |
We offer other Press Brake Machine Specifications, such as follows:
We have passed the CE certificated for Press Brake Machine
Packaging
Press Brake Machine: Standard export packing or according to customers request
Shipping
By Sea
Payment Terms:30% advance payment,70% payment after receive the T/T single
Warranty: 1 year
1.Free installation, trial start and adjustment, training. But the machine quotation does not include the charges of our engineers in the buyer's country if you want, and the buyer must take charge of all the expenditure including airline tickets of our engineers when in the buyer's country to do the service!
2. Warranty period is 1 years. During the warranty period we shall reply to the call or Fax from the user for the machine faults (expect for faults caused by no abiding by the relevant operation regulations, or by for ce injury) within 24 hours.
1. With 7 years of production experience
2. Producing all columns of hydraulic press. single-column hydraulic presses, double-column hydraulic machines, four-column hydraulic machines, hydraulic pressure management systems, hydraulic straightening machines, hydraulic machines and other machines, totally 8 series and 150 varieties.
3. Can be customized production of various types of non-standard Pressing Machine
This is our factory for manufacture Press Brake Machine
This is our workshop for manufacture Press Brake Machine
