High Speed Laser Solar Cell Cutting Machine With Smooth Cutting Edge
US$ 8,000 - 12,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Laser Type:
Fiber Laser
Applicable Material:
Other, Silicon Wafer
CNC or Not:
No
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Keyland Laser Dicing Machine for Solar WaferUS$ 9,000 - 15,000MOQ: 1 Set -
Keyland Silicon Wafer Laser Dicing Machine With Servo Motor and X-Y Working TabelUS$ 9,000 - 15,000MOQ: 1 Set
-
Low Cost Solar PV Industry Fiber Laser Solar Cells Cutting Machine for Solar Panel Assembly LineUS$ 1 - 25,000MOQ: 1 Set
-
Factory Direct Price Diode Side Pump Laser Marking Machine 50w 75w 100wUS$ 5,000 - 9,000MOQ: 1 Set
-
Keyland Solar Cell Cutting Fiber Laser Machine for Broken Solar Cell ScribingUS$ 9,000 - 15,000MOQ: 1 Set
Laser Type
Fiber Laser
Applicable Material
Other, Silicon Wafer
CNC or Not
No
Control Software
Lasercut
Graphic Format Supported
AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Cooling Mode
Air Cooling
Place of Origin
Jiangsu, China
Brand Name
Keyland
Model Number
GSC10F
Certification
CCC, CE, GS, ISO, SGS, UL
After-sales Service Provided
Engineers available to service machinery overseas
High Speed Laser Solar Cell Cutting Machine with Smooth Cutting Edge
Application
Scribing means, cutting of a grid pattern of grooves in a semiconductor material generally for the purpose of marking interconnections or to cut the solar cells into two parts.
Advance
Compared to mechanical machining and chemical treatment, the laser offers wonderful process control, the process is cost-efficient and gentle to the material.
Principle
The fundamental process of most laser structuring applications on solar cells is the direct laser-induced vaporization and melt ejection by nanosecond laser pulses. The structuring processes, which are already used in many industrial pilot- and volume productions, offer big advantages due to their high speeds
Solar cells have been cut into any shapes & sizes.
- Smaller pulse width, higher peak power brings faster cutting speed.
- Auto vac-sorb worktable lower the risk of break cells/wafers.
- Lower cost compared to fiber laser.
- Servo motor optional for high-end market.
- Powerful software easy to operate. It can show the cutting line preview.
- Wonderful cutting edge easy to seperate
Technical Specs
| Model | GSC-50S | GSC-10E |
| Output power | 50W | 10W |
| Cooling way | Water | Air |
| Wavelength | 1.06μm | |
| Scribing line width | 50μm | |
| Max scribing speed | 120mm/s | |
| Scribing accuracy | ±10μm | |
| Laser repetition frequency | 20KHz-100KHz | |
| Worktable moving speed | ≥80mm/s | |
| Working table | Automatic vacuum 350*350mm |
|
| Temperature control accuracy | 0.5°C | |
| Power supply | 380V/220V, 50Hz, 3kVA |
|
DEMO VIDEOS
(copy the link to a new tab to watch)
| Laser cutting solar cell | http://youtu.be/fPheJhxrx0Y |
| Laser cutting wafer | http://youtu.be/LWOcysXYzUI |
| Laser cutting solar cell 2 | http://youtu.be/85L0umXcTzI |
