SLW1400me Veneer lathe:1. Fit for process of stiff wood;
2. Addition of underside slide-way to ensure planeness of veneer.
The updated gear type veneer lathe is driven by assembly of electric motor and gear,it is more easier to regulate&repair since the absence of timing meter.To realize varying feeding speed with pure mechanical method ,which avoid uneven shaved veneer either caused by rotation inertia of out of round log in the case of both timing motor and hydraulic edge-free rotation shaver or caused by unstsble electric voltage.It is ensured that the shaved veneer thickness is within 0.1mm error under normal situatiaon.
Primary features:
1.Adoption of triple ground shaft and addition of underside slide-way helps to ensure more equal, more stable edge feeding,as result the shaved veneer is of better planeness.
2.Fit for miscellaneous wood, eucalypt wood,deal wood,poplar or other soft wood.
3.The planeness of shaved veneer is controled not manually but by well programmed curve,which is designed when the machine id manufactured.whatever specification the veneer is,it sticks to the same planeness.
4.With adoption of electromagnetic clutch ,the swift and facilitated advance and retreat is ensured.
5.Moderate requirement to works%27technology grade.
SLW1400me Gear Type Wedge-free Rotation Shaver | |||||
Type |
Dia |
Processing length |
Final dia |
Speed |
Depth |
SLW1400me |
260 (mm) |
1300 (mm) |
30(mm) |
30(m/min) |
0.4-3.6 (mm) |
Type |
Weight |
Roller dia |
Power |
Outer measure |
Knife fixation |
SLW1400me |
3200 (kg) |
99(mm) |
19(kw) |
3000×1800×1100(mm) |
Obverse fixation |
Material |
Straight log or remained log core from wedge shaver |
||||
