CIMC RUIJIANG is a special vehicle manufacturer that belongs to CIMC group and is located in Wuhu, Anhui province. The company possesses assets worth of 160 million US Dollars with total area of 330000 square meters; the plant area encompasses approximately 90000 square meters. We have international advanced production lines for concrete mixers, powder tankers, liquid tank trucks, aluminum alloy tank trucks, dump trucks, semi-trailers. The company produces more than 300 varieties of special vehicles of more than 10 series. CIMC RUIJIANG has won a lot of titles: “National Hi-tech Enterprise”, “National Torch Plan Enterprise”, “The Famous Brand of Anhui Province”, “Anhui Province Quality Award” etc. and owns more than 600 national patents.
| Foton Auman Tx 6X4 Dump Truck | ||||
| item | unit | parameter | ||
| Vehicle model | WL5251Z Dump Truck | |||
| Chassis model | BJ3253DLPJH-S | |||
| Overall dimensions | mm | 9950×2500×3450 | ||
| Fact loading | kg | 12805 | ||
| Mass in working order | kg | 12000 | ||
| Body dimensions | mm | 7300×2280×950,800 | ||
| Wheel base | 4700+1350 | |||
| F/R track base | 2005,1865/1865 | |||
| Approach/departure angle | ° | 21/12 | ||
| Engine type | WP10.290 | Exhaust/Power(ml/kw) | 9726/213 | |
| WP10.336 | 9726/247 | |||
| Tire specification | 11.00-20,11.00R20,12.00-20,12.00R20 | Max speed(km/h) | 85 | |
| Traction system | 6×4 | Transmission | RT11509C | |
| Number of axles | 3 | Electric system | 24v | |
| Operation control system | Power steering | Allowable passengers in cab | 3 | |
| Equipment | Equipped with dustbin, hydraulic system and operating system.Pressure is large, operation is convenient and security is dependable. | |||
| Engine | Weichai Power Co.,Ltd (Europe II) | |||
| Production cycle | 20-25 days | |||
| Warranty | 12 month, from the date of supply | |||
1. Why you choose us?
CIMC RUIJIANG is a special vehicle manufacturer that belongs to CIMC group .We have more than 10 years produce experience.And our company produces at least 300 varieties of special vehicles of more than 10 series.
2. How to trust us?
Following the business philosophy of our company which is“your partner for modern transportation”,the sales network of CIMC RUIJIANG has been covering China mainland and global markets including Asia, Africa, South America, East Europe, etc. and welcome visits our company at any time.
3. How about the delivery time?
Most of our trucks are all have in stock ,We can delivery to you within 7 days, if specially ordered , we always need around 30 days for production.
4.How do you ensure the quality of product?
Our Factory is standard production workship,got ISO CCC BV Certification,our workers are well trained. Our very product under goes a scrutinizing inspection process.
