Horlion Generator Price List Generators for Sale 1000kva Generator

Name: Horlion Generator Price List Generators for Sale 1000kva Generator
Brand: HORLION
SKU: 119466225

US$ 3,000 - 17,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

HORLION

Model Number:

HL800GF

Shenzhen Horlion Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO/SHANGHAI/SHENZHEN/GUANGZHOU

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name HORLION

Model Number HL800GF

Output Type AC Three Phase

Speed 1500RPM/1800RPM

Frequency 50HZ/60HZ

Rated Power 800kw

Rated Voltage 220v/230v/380v/400v

Rated Current 1450A

Horlion generator price list generators for sale 1000kva generator

Diesel genset specifications:

1.Coupled with diesel engine and Stamford, Marathon,Leroy somer,Siemens,ENGGA alternator

3..Brushless, Self-excited, IP23, insulation class H alternator

4.40°C radiator as standard, 50°C is optional

5.Key start panel control system as standard, digital auto-start panel is optional

6.Optional open type or silent type

2.Diesel genset parameter:

1.Main technical data of industry gensets
1.1	Model	JGC800GF
1.2	Prime power	800KW/1000KVA
1.3	Prime voltage	230/400V
1.4	Speed	1500 rpm
1.5	Weight	8800kg
1.6	Overall dimension	1670×850×1270mm (just for reference)
2.Main technical data of engine
2.2	Model	KTA50-GSB
2.3	Prime power	880KW/1100KVA
2.4	Governor type	Electronic
2.5	Configuration	4 cycle , 6 cylinder in line
2.6	Air Intake System	Natural Aspirate
2.7	Bore/Stroke	159×159mm
2.8	Displacement	37.8 L
2.9	Starting method	Electric
2.10	Compression ratio	14:1
2.11	Fuel consumption	196g/kw.h
3. Main technical data of alternator
Alternator is selected the new type brushless alternator designed by US Marathon Electric, which has a unique design, advanced structure, small size, light weight, excellent performance, reliable running and easy-to-use operation.
3.1	Brand	MARATHON
3.2	Model	MX-1350-4
3.3	Prime power	850KW/1062.5KVA
3.4	Configuration	Brushless , self-exciting
3.5	Prime voltage	230V/400V
3.6	Frequency	50 HZ
3.7	Power factor	0.8(lagging)
3.8	Phase/wire	3 phase 4 wires
3.9	Isolation	H
