QD pneumatic casing elevator/spider is applicable for casing of 60~622mm(23/8~241/2 in) It features labor saving, safe and pneumatic operation.
It is a kind of ideal tool for casing operation.It is designed and manufactured according to API Spec 8C “Specification For Drilling and Production Hoisting Equipment”
Specification Series and Performance Parameters:
Model |
QD622-450(API500) |
QD340-450(API500) |
QD340-315(API350) |
QD140-135(API150) |
||
Applicablerange |
mm |
324-622 |
113-340 |
113-340 |
60-139.7 |
|
in |
123/4~241/2 |
41/2-133/8 |
41/2-133/8 |
23/8-51/2 |
||
Ratedload |
kN |
4500 |
4500 |
3150 |
1350(31/2)900(51/2) |
|
USton |
500 |
500 |
350 |
150(31/2)100(51/2) |
||
Pressure |
MPa |
0.5-0.9 |
0.5-0.9 |
0.5-0.9 |
0.5-0.9 |
|
psi |
72-130 |
72-130 |
72-130 |
72-130 |
||
Size |
elevator |
mm |
1886×1470×1070 |
1390×1290×915 |
1335×1040×806 |
990×730×550 |
in |
74.3×57.9×42.1 |
55×51×36 |
52.5×41×31.7 |
39×28.7×21.6 |
||
spider |
mm |
1886×1470×970 |
1390×1290×970 |
1335×1040×872 |
810×730×560 |
|
in |
74.3×57.9×38.2 |
55×51×38 |
52.5×41×34.2 |
31.9×28.7×22 |
||
Weight |
kg |
12000 |
9900 |
7550 |
1430 |
|
lb |
26450 |
21820 |
16640 |
3152 |
||
