Help CenterCYB44TH(XG) Suspension Pump
Related Products
Specifications
Suspension Pump1. API11AX
2. Long service life;
3. Competitive price;
4. Best service,good quality
Suspension Pump
Product Features:
The barrel of the pump is suspended, so the load on the barrel is small and the deformation of the barrel is small so as to avoid sticking pump because of the elongation and attenuation of the barrel. As compared with the common pumps, the pump is longer in life.
It is mainly composed of barrel assembly, plunger assembly and outer tube assembly.
Technical Specifications of Suspension Pump :
Type |
25-150TH(XG) |
25-175TH(XG) |
CYB38 TH(XG) |
CYB44TH(XG) |
|
Nominal Diameter |
38.1/38 |
44.5/44 |
Plunger Length |
1219/1200 |
|
Barrel Length |
3000-9000 |
|
Upper Connection of Tubing |
2-7/8NU/EU |
2-7/8NU/EU |
Bottom Connection of Tubing |
2-7/8NU/EU |
2-7/8NU/EU |
Size of connecting Sucker Rod(mm) |
3/4 |
|
Pump Constant(m3/d) |
1.642/1.633 |
2.235/2.190 |
Max.O.D.(mm) |
107 |
|
The Max. well depth |
2800 |
2300 |
