2015 Full Automatic Infrared Bridge Type Edge Cutting Machine
US$ 24,000 - 26,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
TIANJUN
Model Number:
TJQH-800
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2015 Infrared Automatic Bridge Type Edge Cutting MachineUS$ 21,000 - 22,000MOQ: 1 Unit -
2.8kw Power 300mm Blade Automatic Stone SawUS$ 2,000 - 5,000MOQ: 1 Unit
-
Small Portable Site Cutting Machine, Machine Made in ChinaUS$ 1,300 - 1,800MOQ: 1 Set
-
TJ New Wholesale Portable Machine, Best Stone Cutting Machine PriceUS$ 1,000 - 1,200MOQ: 1 Set
-
Stone Cutting Machine, Wet Saw Tile CutterUS$ 1,000 - 1,200MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
TIANJUN
Model Number
TJQH-800
Stone cutting machine, machine for tile specification cutting
Cutting machine,edge cutting machine,stone equipment,bridge type edge cutting machine,stone machine
Description:
1.Bridge movement by means of precise linear guide ways
2.Z axis movement by lead screw
3.Magnetic rule for slicing measure
| Technical data | ||||||||
| Name | Unit | TJQH-800 | ||||||
| Diameter of blade | mm | 400~800 | ||||||
| Up and down stroke of blade | mm | 400 | ||||||
| Main motor power | kw | 18.5 | ||||||
| Feeding motor | kw | 3 | ||||||
| Slicing motor | kw | 1.1 | ||||||
| Max. cutting size | mm | 3200×2000 | ||||||
| Rotation angle of worktable | 90°or 360° | |||||||
| Upturning angle of worktable | 0°~85° | |||||||
| Dimension | mm | 6300×4700×2800 | ||||||
| Gross weight | kg | 6800 | ||||||
Stone edge cutting machine photos:
QUALITY CONTROL:
STONE FAIR:
OUR COMPANY:
OUR CUSTOMERS COVER:
Contact US:
