Stone Cutting Machine, Cutting Edge
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
TIANJUN
Model Number:
TJQH-800
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2016 TJQH-600 Tile Making MachineUS$ 17,200 - 18,000MOQ: 1 Unit -
Stone Cutting Machine, Tile Cutting MachineUS$ 17,200 - 17,800MOQ: 1 Unit
-
Bridge Type Stone Cutting Machine, Floor Tile Making MachineUS$ 17,200 - 17,800MOQ: 1 Unit
-
Infrared Stone Edge Cutting Machine,Machines for Manufacturing Ceramic Tiles Quality ChoiceUS$ 17,000 - 19,000MOQ: 1 Set
-
Infrared Fully Automatic Bridge Type Edge Cutter,tile CutterUS$ 18,000 - 23,000MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
TIANJUN
Model Number
TJQH-800
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.Bridge movement by means of precise linear guide ways2.Z axis movement by lead screw
3.Magnetic rule for slicing measure
Stone cutting machine, machine for tile cutting, cut machine
Cutting machine,edge cutting machine,stone equipment,bridge type edge cutting machine,stone machine
Description:
1.Bridge movement by means of precise linear guide ways
2.Z axis movement by lead screw
3.Magnetic rule for slicing measure
| Technical data | ||||||||
| Name | Unit | TJQH-800 | ||||||
| Diameter of blade | mm | 400~800 | ||||||
| Up and down stroke of blade | mm | 400 | ||||||
| Main motor power | kw | 18.5 | ||||||
| Feeding motor | kw | 3 | ||||||
| Slicing motor | kw | 1.1 | ||||||
| Max. cutting size | mm | 3200×2000 | ||||||
| Rotation angle of worktable | 90°or 360° | |||||||
| Upturning angle of worktable | 0°~85° | |||||||
| Dimension | mm | 6300×4700×2800 | ||||||
| Gross weight | kg | 6800 | ||||||
Stone edge cutting machine photos:
QUALITY CONTROL:
STONE FAIR:
OUR COMPANY:
OUR CUSTOMERS COVER:
