P5 waterproof LED Display Panels HD with 70mm thickness 43624 pixels
1) High brightness : over 6000 nits
2) High definition: 43624 pixels per square meter
3) Waterproof : IP65 standard
4) Super-light: only 7.8 KG per panel
5) Ultra-thin: only 70mm thickness
Product Description
1. SMD3-in-1 technology are used for indoor LED display.
2. Wide view angle: 140 in horizonal and 140 in vertical
3. Special design and advanced SMT technology improves the heat dissipation
4. With high refresh rate controller, guarantee that no scan line when taking photos.
5. Slim and lightweight design.
6. Easy for assembling and connecting with fast lock and the connector added.
7. High color uniformity and clear image can bring you a vivid audio visual effect.
8. Items: P3,P3.75,P4,P5,P6,P8 etc
what is the advantages of our P5 led display moudle?
1.High quality:
our most basic guarantee: the aging time exceeding 24 hours. Malfunction dot rate less than 0.0001. MTBF more than 10000 hours.we assure high brightness and long lifespan.
2.Perfect Display Effect:
High brightness and clearly led display effect with easy use control system which allow you easy become enviable led display experts.
3.Attractive Factory Price:
We are a professional manufacturer, has its own factories and production lines. Without middlemen and trading companies, our price is more competitive, quality is more reliable.
4.Auto equipment:
kailite has several auto production lines equipment with Taiwan auto-encapsulate machine, Taiwan Chang-Yu handler, and the production of LED meets the demand of high quality standard LED display.
| Model | P4.81 ( P5 ) Die-casting LED display for rental outdoor |
| Pixel pitch | 4.81 mm |
| Pixel density | 43,264 dots / sqm |
| Module size ( W * H ) | 250 mm ( width ) * 250 mm ( height ) |
| Module pixels ( W * H ) | 52 dots *52 dots |
| Pixel configuration | 1 Red 1 Green 1 Blue |
| Drive mode | constant current driving 1 / 13 scan |
| LED lamp type | SMD2727 waterproof |
| Cabinet size ( W * H ) | 500mm * 500mm |
| Cabinet resolution | 104*104 dots |
| Net weight | 7.8 Kg / cabinet |
| Color scale | 65,536 degree |
| View angle ( H / V ) | 140 / 120 degree |
| Brightness (White balance) | about 6000 cd / sqm. |
| Power consumption ( one cabinet ) | Max : 200 Wattte / cabinet , Average : 100 Watte / cabinet |
| Inputting Voltage | 90 - 264 VAC |
| Operating temperature | - 30 °C ---- + 60 °C |
| Operating humidity | 10%—95%RH |
| Life time | ≥ 100,000hours |
| MTBF | 5,000 hours |
| Whole Display Flatness | ≤ 0.5mm Juncture |
| Frame frequency | 25-60 Hz/s |
| Refresh rate | ≥ 2,000Hz /s |
| Control distance |
100m ( without repeater ) , single mode fiber : 20km , multi mode fiber : 500m |
| LED control system | LINSN , Nova-star , Colorlight are selectable |
| Operating system | Windows Xp / Windows 7 / windows 8 / 8.1 / windows 10 |
| Protection grade | IP65 |
| Maintenance way | Rear Access |
Usually, there are three tyeps of package design.
Firstly, we pack the LED display in the paper carton.
Secondly, we will pack the LED display in the flight case if customer request for frequent movement.
Thirdly, the favorable package method is wooden case package because of its lower cost and instant usage.
1. Pre-sales service:
a) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
b) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection.
2. After-sales service:
a) Service principles: response in time, solve problems as soon as possible and ensure the use.
b) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
c) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
d) Under normal use and storage, Our Company will be responsible for the equipments.
Repair Service for LED Display Lifelong time
