Specifications
Automatic Sleeve Labeling Machine1. labeling, oven, steam generator
2. 150-450 bottle/minute
3. body, neck, full body label
Automatic Sleeve Labeling Machine
Features:
All-cover type stainless steel host machine: the whole machine is waterproof as well as rustproof.
Adjustable cutter head: unique cyclotron cut-off, double sided cutting edge with a long service life.
Single positioning centre guide pillar: more stable for label delivery.
Synchronous bottle divider: a more stable transmission for the bottle.
Bottom set label brush: more precision for casting label.
Label-controlling electric-eye shelf: unique combination of tail and electric-eye to improve the precision for cutting off the membrane materials.
Push-button control cabinet: a more humanized operation.
Independent feeding material shelf: the position of the material shelf is optional at will.
Electrical Appliance Configuration Specification
It adopts PLC programmable controller, imported servo motor, servo driver, frequency converter and transducer; also, it adopts the positioning module to ensure the casting label precise, rapid and stable.
Applicable Variety Types of Label.
Various kinds of bottle types, for example: round bottle, square bottle, flat bottle, curve bottle and cup-shaped, etc.
| SLM-150/250 | Technical Parameters | |
| Model | SLM-150 | SLM-250 |
| Input Power | 1.5KW | 3.0KW |
| Input Voltage | 3,380/220VAC | 3,380/220VAC |
| Production Efficiengcy | 150Bottle/min | 250Bottle/min |
| Size of Host Machine | L2100mm x W850mm x H2000mm | L2100mm x W850mm x H2000mm |
| Applicable Diameter of Bottle Body | Φ28mm-Φ125mm | Φ28mm-Φ125mm |
| Applicable Length of Lable | 30mm-250mm | 30mm-250mm |
| Applicable Thickness of Label | 0.03mm-0.13mm | 0.03mm-0.13mm |
| Applicable Internal Diameter of Paper Tube | (Free Adjustment) | (Free Adjustment) |
