Silicone Rubber Insulated and Sheathed Flexible Control Cable

Name: Silicone Rubber Insulated and Sheathed Flexible Control Cable
Brand: New Baofeng
SKU: 119876127

Negotiable MOQ: 500 Amperes (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

New Baofeng

Application:

Instrumentation

Hebei New Baofeng Wire & Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name New Baofeng

Application Instrumentation

Conductor Material Copper

Insulation Material PVC

Jacket Other, Teflon

Specifications

1.Professional manufacturer
2.Reliable quality&competitive price
3.Delivery in time

copper condcutor, PVC or PE insulation, copper wire screen PVC outersheath control cable used for comupter, equipment and so on.

1.Product standardThis product is manufactured according to GB9330 and enterprise standards.

For system connection wire of control, signal, protection or measuring with rated voltage up to and including 450/750KV.

2.Operating characteristics

Permissible Max. continuous operating temperature of conductor:

PVC insulated: 70°C; XLPE insulated: 90°C

Upon short circuit (Max. Duration time 5s) the Max.

Temperature of conductor not higher than:

PVC insulated: 160°C; XLPE insulated 25°C0.

Ambient temperature of installation not less than 0°C

Preferred Permissible bending radium:

For non-armored cable, not less than 6 times of cable diameter;

For armored or copper-tape-screened cable, not less than 12 times of cable diameter;

For screened flexible cable, not less than 6 times of cable diameter.

Type, designation and application

Type	Designation	Main applications
KVV/KYJV	Copper conductor PVC/XLPE insulated PVC sheathed control cable	For fixed-laying indoors, in cable duct or conduit
KVVP/KYJVP	Copper conductor XLPE/PVC insulated PVC sheathed braid screened control cable	For fixed-laying indoors, in cable duct or conduit upon screen requirement
KVVP2/KYJVP2	Copper conductor PVC/XLPE insulated PVC sheathed copper tape screened control cable	For fixed-laying indoors, in cable duct or conduit upon screen requirement
KVV22/KYJV22	Copper conductor PVC/XLPE insulated PVC sheathed steel tape armored control cable	For fixed-laying indoors, in cable duct direct-buried, able to bear larger mechanical forces
KVV32/KYJV32	Copper conductor PVC/XLPE insulated PVC sheathed fine steel wire armored control cable	For fixed-laying indoors, in cable duct, conduit or well, able to bear larger mechanical forces
KVVR/KYJVR	Copper conductor PVC/XLPE insulated PVC sheathed control flexible cable	For laying indoors upon moveable requirement
KVVPP/KYJVPP	Copper conductor PVC/XLPE insulated PVC sheathed braid screened control flexible cable	For laying indoors upon moveable and screen requirement
