Help CenterJumbo Bag Packaging Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, all kinds of loosing materials
Packaging Type:
Other, Jumbo bags
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo Tianjin Guangzhou Shenzhen etc.
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Application
Other, all kinds of loosing materials
Packaging Type
Other, Jumbo bags
Packaging Material
Other, Paper, PP PE,Paper,etc
Automatic Grade
Automatic
Driven Type
Electric
Power
4kw
Place of Origin
Jiangsu, China
Brand Name
M&J
Model Number
LCS-MT
After-sales Service Provided
Engineers available to service machinery overseas
Certification
CE,ISO9001-2004,CIQ,CQC,etc
Specifications
Weighing range:500-2000kg/bagAccuracy:~0.1%FS
Semi-auto
Capacity:8-16bags/h
Suitable for powder,pellet,mixtures.
Applications:
This scale is special for 500kg level quantitative packing function field. It can support up to 2000kg per bag of materials such as monosodium, starch, coal-powder, cobblestone, PVC, EPS, additive, urea, malt, cotton, seed, soybean and all kinds of crystallization, etc.
Features:
This Machine has stainless steel mode, which is made up of stainless steel. This mode is very suitable for the corrosive chemical material and food safety requirements material.
This Machine has stainless steel mode, which is made up of stainless steel. This mode is very suitable for the corrosive chemical material and food safety requirements material.
Flowing Processes:
Bag supplied & clamped by manual→ Automatic filling→ Automatic weighing→ Automatic bag conveying
Main Structures:
1. Automatic filling system
2. Automatic weighing balance
3. Ton-bag clipper
4. Automatic belt conveyors
5. Electric control cabinet
Technical Parameters:
Precision |
±0.1%FS |
Weighing scale ( kg/bag) |
500~2000 ( can be a adjusted freely) |
Power Supply |
220Va.c or 4N-380Va.c 50/60 |
Power Dissipation (kw) |
6.5 |
Compressed Air (MPa) |
0.4~0.6 |
Compressed Air Consume (m3/h) |
0.5 |
