Specifications
Achitecture facade1.Meterial:SS 304.316
2.Process:Woven
3.Usage:Suspended ceilings, Walls, Columns cladding floors
Metal facade,Achitecture fabric,decorative mesh,Architecture facade
Metal fabrics, with its versatility, unique texture, variety of colors, durability and flexibility
Metal fabrics offers an extraordinary collection of woven metal fabrics designed, engineered and manufactured specifically for the architecture community. Our fabrics are produced in various weights, weaves, and degrees of transparency and flexibility and suitable for both interior and exterior applications.
Metal fabrics have been specified by architects and designers throughout the world for exterior facades, sunscreens ,suspended ceilings, walls, columns cladding floors and infill.
|
Model |
Material |
Weft Rod diameter |
Rod pitch |
Warp Cable diameter |
Cable pitch |
Weight |
SC22 |
Brass |
0.5mm |
1.6mm |
0.4mm(1x7) |
3.7mm |
2.1kg/m2 |
SC39 |
Copper |
2.0mm |
8.0mm |
2.5mm(7x7) |
6.0mm |
8.5kg/m2 |
SL18 |
AL |
2.0mm(flat rod) |
4.2mm |
1.5mm |
17.5mm |
2.3kg/m2 |
SPC22 |
P-Copper |
0.5mm |
1.8mm |
0.4mm(1x7) |
3.7mm |
1.9kg/m2 |
SSA30 |
SS304,316 |
1.6mm |
50mmx50mm |
|
|
0.6kg/m2 |
SSY30 |
SS304,316 |
1.5mm |
1.5mm |
2.0mm |
8.3mm |
12.3kg/m2 |
SA21 |
SS304,316 |
1.5mm(flat rod) |
3.8mm |
2.0mm(1x19) |
17.5mm |
5.0kg/m2 |
SA22 |
SS304,316 |
0.5mm |
1.8mm |
0.4mm(1x7) |
3.7mm |
1.65kg/m2 |
SA26 |
SS304,316 |
3.0mm |
6.0mm |
2.0mmx4(7x7) |
55mm |
11.1kg/m2 |
SA29 |
SS304,316 |
3.0mm |
10mm |
2.0mm(1x19) |
80mm |
5.9kg/m2 |
SA36 |
SS304,316 |
3.0mm |
10mm |
3.0mm(7x7) |
5.0mm |
14kg/m2 |
SA37 |
SS304,316 |
1.5mm |
3.0mm |
0.75mmx4(1x7) |
26.4mm |
5.2kg/m2 |
SA294 |
SS304,316 |
3.0mm |
10mm |
2.0x3(1x19) |
80mm |
5.9kg/m2 |
SA394 |
SS304,316 |
2.0mm |
8.0mm |
2.5mm(7x7) |
6.0mm |
7.5kg/m2 |
