SAKO SKN-M Series Pure Sine Wave Inverter

SAKO SKN-M Series Pure Sine Wave Inverter thumbnail-1
SAKO SKN-M Series Pure Sine Wave Inverter thumbnail-2
SAKO SKN-M Series Pure Sine Wave Inverter thumbnail-3
SAKO SKN-M Series Pure Sine Wave Inverter thumbnail-4
SAKO SKN-M Series Pure Sine Wave Inverter thumbnail-5
SAKO SKN-M Series Pure Sine Wave Inverter photo-1
SAKO SKN-M Series Pure Sine Wave Inverter photo-2
SAKO SKN-M Series Pure Sine Wave Inverter photo-3
SAKO SKN-M Series Pure Sine Wave Inverter photo-4
SAKO SKN-M Series Pure Sine Wave Inverter photo-5
US$ 35 - 1,000 MOQ: 50 Units
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SAKO,OEM, ODM
Model Number:
SKN-M500VA/1000VA/2000VA/3000VA/5KVA/7.5KVA/10KVA
Contact Supplier Request Quote Chat Now
Sako Electrical Group Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SAKO,OEM, ODM
Model Number SKN-M500VA/1000VA/2000VA/3000VA/5KVA/7.5KVA/10KVA
Output Power Other, 500W-10KW
Output Type Single
Weight 6-78KG
Input Voltage DC:12V,24V,48V,96V,192V
Output Voltage 110V/220V
Type DC/AC Inverters
Output Frequency 50/60HZ
Output Current 2.7-45A
SAKO SKN-M  SERIES PURE SINE WAVE INVERTER
Micro Processsor Control
Pure Sine Wave
Intelligent Automatic Voltage Regulating Technology
Intelligent Automatic Voltage Charging Technology
over load,short circuit protection
Overtemperature protection
By Pass system
Automatic charge even inverter is off
Shut off output by manual if no need power
Low battery protection
Over voltage, Low voltage proction
Compatibility with generators
The LED &LCD Display Design Option


MODEL SKN-M500W SKN-M1KW SKN-M2KW SKN-M3KW SKN-M5KW SKN-M7.5KW SKN-M10KW
SPECIFICATION
DC INPUT
Input Voltage(Vdc) 12 24 24/48 48 96 144 192
Input Current(A) 56A 54A 100/51A 76A 63A 63A 63A
Input DC Range(Vdc) 10~14 20~28/40~56 40-56 80-110v 120-164v 160-219v
AC BYPASS
Input AC Range(Vac) W/O AVR:100-260VAC         With AVR:165-260V
Input Frequency Range(Hz) Same as the City power
Input Current(A) 5 10 24 30 40 60 80
Charge Current 8-12AP 15-20A P 15-40A P
Transfer Time(ms) UPS Setting :<=4 ms/ Generator :<=1s
AC OUTPUT
Capacity(VA) 500 1000 2000 3000 5000 7500 10000
Output Power(W) 500 1000 2000 3000 5000 7500 10000
Output Voltage 220VAC+-3%
Output Frequency 50HZ/60HZ
Output Current(A) 2.2 4.5 9 13.5 23 34 45
Voltage Precision(VAC) 220±3%
Frequency Precision(HZ) 50±1%/60±1%
Wave Distortion(TCKJ) <=5%
Power Factor(PF) 1
Overload Capacity 100%~120%, 25 mins, 120%~200%, 1 mins, >200%, 0.1 mins
Inversion Efficiency 100%
Bypass Transfer time(ms) <=4 ms
PROTECTION
Protection over temperature/ over load/ over voltage/
 low battery/ low voltage/ Input low/ hight voltage/ short current protection
AMBIENT
Noise(dB) <=40 (1 mter)
Temperature -20~45 degree
Humidity 0~95% ( no condensation)
Sea Level(m) <=1500
DIMENSION
Package L×W×H 520×240×327 600×335×475
Weight(Kg) 9.5 15 22 28 44 56 66

The final specs according to the sales offered.
