Telecommunications Power Supply SK11 Series

Telecommunications Power Supply SK11 Series thumbnail-1
Telecommunications Power Supply SK11 Series photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SAKO
Model Number:
SK11
Contact Supplier Request Quote Chat Now
Sako Electrical Group Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SAKO
Model Number SK11

Specifications

Feature:
1)Single phase in, single phase out
2)True On-line double conversion design providing all power prote

TECHNICAL PARAMETER
Model SK11 series
Capacity 2KVA 3KVA 5KVA 6KVA 8KVA 10KVA 15KVA 20KVA
Power(W) 1.6KW 2.4KW 4KW 4.8KW 6.4KW 8KW 12KW 16KW
Power Factor 0.8
Input
Phase single phase
Voltage Range 220VAC (160 ~ 300Vac)
Frequency Range 50Hz±5%
Input powe factor ≥82%
Output
Phase single phase
Wave form pure sine wave
Crest Factor 3:1
Rated voltage 220Vac±1%
Transient response 0ms
Frequency 50Hz
Frequency stability 50Hz ±0.5% battery model
Total harmonic distortion < 3%
Short circuit current automatic protection
Overload capacity ≥120% 1min , ≥150% 30Sec
Efficiency AC to AC ≥89%
Battery
Battery Maintenance free lead-acid battery
Battery QTY 16pcs
DC Voltage 192VDC
Charge current 3A,5A,10A option
Charging time less than 10 hours
Battery efficiency >90%
Back up time Any configuration for battery power supply time
System
Communication interface RS232(SNMP,modem optional)
LCD Display Input/output voltage and frequency,battery voltage, output load, mainpower or load false records
LED Display UPS running status, battery status,load status, false status
Alarm warning main power false, rectifier PCBA false,low battery, over load,UPS false
silence Automatic
Running temperature 0 ~ 40°C degrees Celsius
Relative Humidity Less than 95%(without condensing)
Altitude 1000m output nominal power   (with increase of 100m,it will reduce output of 1%)max 4000m
Noise at 1M less than 50dB
Degree of protection IP20
Applicable Standards IEC62040
long time backup NW.(Kg) 30 31 60 62 90 100
Standard back up NW.(Kg) 60 61 89 91 W/O
Products size (W×D×H) L 230×525×395 230×625×560 310×685×840
Products size (W×D×H) S 230×625×585 230×625×640 W/O
