Specifications
1)400mm Led Traffic Signal Light2)Low power consumption
3)Compatibility with most traffic housings and controllers
Led Traffic Signal Light/Led traffic light/Led traffic lamp/led arrow light
Features & Benefits
(1) Housing material Aluminum
(2) DimensionΦ300mm,
(3) Luminous Intensity Red and yellow 600cd,Green400cd
(4) Chromaticity
Red 625±5nm
Yellow 590±5nm
Green 505±2nm
(5) Power Supply AC220V/110V±20% 50Hz/60HZ
(6) Power ≤10W
(7) Power Factor ≥0.9
(8) Operation Temp. -40~+85
(9)Humidity ≤90%
(10)Life Time 50000h
(11)Weight ≤15kg
(12)Temperature Range:Class B
(13) Impact Resistance: Class IR2
(14) Ingress:IP54
1.Product Summary: | ||||||||||||||
FX400-3C/K traffic signal head which is a today’s fashion product uses LEDS as light sources. It consists of three-color arrow lights with alluminium alloy. Diameter of optical is Φ400mm. | ||||||||||||||
Feature: | ||||||||||||||
In unique reflector design, the light is characterized with wide viewing angle, uniform brightness, standard chromaticity, low power consumption, long life time. These advantages really outstand especially during in the burning sun and smog weather. | ||||||||||||||
2.Range of application: | ||||||||||||||
This light is applied for all necessary arrow traffic road junctions. | ||||||||||||||
3.Product parameter: | ||||||||||||||
Description |
Model |
Drawing Number |
Dimension |
Housing Material |
Housing Color |
|||||||||
400 arrow light |
FX400-3C/K |
FX400-3C/K.00.00.00 |
1457 X 563 X 475mm |
alluminium alloy |
black |
|||||||||
| ||||||||||||||
Color |
Size of Emitting Surface |
Lens Feature |
LEDS |
LED Number |
Central Light Intensity |
Optical Feature |
Voltage |
Rated Power |
Standard |
|||||
red |
Φ400mm |
Flat lens with scaly pattern |
Φ5(0.06W) |
83 pcs |
>6000cd/m2 |
reflector |
AC176 ~ 264V |
≤15W |
GB14887 -2003 |
|||||
yellow |
Φ400mm |
Φ5(0.06W) |
83 pcs |
>6000cd/m2 |
≤15W |
|||||||||
green |
Φ400mm |
Φ5(0.06W) |
83 pcs |
>6000cd/m2 |
≤15W |
|||||||||
4.Dimension: | ||||||||||||||
| ||||||||||||||
