Help Center200mm PC Housing Hi-flux Led Traffic Lights
Related Products
-
300mm Led Traffic Signal LightUS$ 170 - 190MOQ: 5 Sets -
400 U-turn Light-400 Led Traffic LightNegotiableMOQ: 5 Sets
-
400 Led Traffic Signals 400 LED Traffic LampNegotiableMOQ: 5 Sets
-
200mm LEDTraffic Signal LightNegotiableMOQ: 5 Sets
-
LED High-flux Full Ball Traffic Signal LightNegotiableMOQ: 30 Sets
Specifications
1)Hi-flux LED Traffic Signal Lamp2)Low power consumption
3)PC housing led traffic lamp
LED Traffic Signal Light/Led traffic light
Features and Benefits
Conform to ITE standard
Low power consumption
Operating at the temperature of -40°C to +74°C
Retrofit design UV stabilized shell
Wide viewing angles
Even brightness standard chromatogram
Up to 10 times longer lifetime than incandescent
Compatibility with most traffic controllers
Product Characteristics:
Black houisng available
Product name |
Product model |
Product drawing No. |
Product size |
Housing material |
Housing color |
200mm traffic head |
JD200-3-3S |
JD200-3S01.00.00 |
1044X342x368mm |
Polycarbonate housing |
Black or yellow |
Color |
Emitting surface size |
Lens features |
Characteristics of LED |
Number of LED |
Luminous intensity |
Light distribution characteristics |
Voltage |
Rated power |
Meet standard |
Red |
Φ200mm |
Fresnel lens |
Hi-flux LEDs |
2pcs |
>200cd |
Incandescent look |
120vac |
≤10W |
ITE |
yellow |
Φ200mm |
Fresnel lens |
Hi-flux LEDs |
3pcs |
>400cd |
Incandescent look |
≤16W |
||
green |
Φ200mm |
Fresnel lens |
Hi-flux LEDs |
2pcs |
>220cd |
Incandescent look |
≤11W |
Color |
Power factor |
Total harmonic distortion |
Turn on/off time |
Operation temperature |
Chromaticity |
IP (LED Modules) |
IP (Traffic head) |
Red |
>0.90 |
≤20% |
≤75ms |
-40°C~+80°C |
625nm±5nm |
IP65 |
IP55 |
yellow |
>0.90 |
≤20% |
≤75ms |
-40°C~+80°C |
590nm±5nm |
IP65 |
IP55 |
green |
>0.90 |
≤15% |
≤75ms |
-40°C~+80°C |
505nm±4nm |
IP65 |
IP55 |
