Specifications
600volt concentric cable:1.CCC Certificate,ISO9001:2008 Standard
2.Hot sale concentric cable
3.Fast Delivery
600volt concentric neutral copper or aluminum cable :
Concentric Cable Construction
Plain copper conductors, IEC 60228, solid or stranded versions, conductor types
10-16 mm² round, solid conductors (re) alt.
10-25 mm², stranded conductor (rm),
35-240 mm², sector shaped conductor, stranded (sm)
PVC conductor insulation
Conductors stranded concentrically
Filling compound
Concentric conductor (Ceander), inner layer of corrugated copper wires, outer layer with copper tape
PVC outer jacket
Jacket color: Black
Application
Power cables for energy supply are used for industry and distribution boards, power stations, house connecting boxes and street lighting as well as control cable for the transmission of control impulses and test data.
Overall, where increased electrical and also mechanical protection are required.
Those cables are installed in open air, in underground, in water, indoors and in cable ducts.
The concentric conductor (C) is allowed to use as PE-, PEN-conductor or as shield.
due to the typical construction of concentric conductors it is possible to obtain many more cable joints, without cutting any conductor. In that way the operating reliability is guaranteed.
