800kw Diesel Generating Set
This 800kw diesel generator set is powered with MTU engine.
Specification of genset
Genset model:HL800GF
Prime power: 800KW/1000KVA
Standby power: 880KW/ 1100KVA
Power factor: 0.8
Rated Voltage: 400/230V
Rated frequency (HZ): 50
Dimensions (mm) (L×W×H): 4400×1750×2300
Weight (kg): 7025
Specification of diesel engine
Engine Model: 16V2000G65
Manufacturer: MTU
Governor: ECM
Air intake way: Turbo-charged
Cylinders/Arrangement: 16/V
Bore× Stroke(MM): 130×150
Fuel Consumption Rate(L/h): 198
Lubricating oil capacity(L): 102
Coolant capacity (L): 200
Engine speed (rpm): 1500
Max Power (kW): 979
Starting Method: DC24V electrical starting
Specification of alternator
Alternator model: HLF800
Connecting Type: 3 Phase and 4 Wires
Number of Bearing: 1
Protection Grade: IP21
Altitude: ≤1000m
Exciter Type: Brushless, Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation Class: H
Telephone Influence Factor (TIF):≤50
Voltage Regulation, Steady State: ≤±1%
Transient State Voltage: ≤-15%~+20%
Control System
Operating temperature: -20°C~60°C
Relative Humidity: 95%
Operating voltage: DC24V (range: 18-30V, pressure: 50V/5 mm )
Standard functions: Engine Control/Generator Monitoring/Generator Protection/Engine Monitoring/
Clear Text Display
Shutdown: Loss of Speed Signal,Alternator Under / Over Voltage,Alternator Under/ Over Frequency,
Mains Under / Over Voltage,Mains Under/ Over Frequency,Under / Over Speed,Low Oil Pressure,
High Engine Temperature,Phase Sequence Electrical (Option),Earth Fault (Option)
Warning: Alternator Under / Over Voltage,Alternator Under/ Over Frequency,Mains Under / Over Voltage,
Mains Under/ Over Frequency,Under / Over Speed,Low Oil Pressure Pre-Alarm,High Engine Temperature Pre-Alarm,High/Low Battery Voltage,Over-current,Periodic maintenance
GENEST TYPE:
OPEN TYPE
SILNT TYPE
TRAILER TYPE
PRODUCTION LINE:
PACKING:
CERTIFICATES:
OUTLOOK OF OUR FACTORY:
Contact information:
