vacuum high efficient plank/wood chips drying kiln equipment
plank drying kiln equipment : Main parameter
HF vacuum dryer is a kind of drying machine with low temperature in vacuum situation, smaller but much faster than the conventional kilns.
Model |
GZ-8.0III-DL |
Capacity |
8.64 CBM |
Out Dimension (mm) |
L7600xW2000xH2090 |
Inside dimension (mm) |
L6800xW1750xH1750 |
Timber cart (mm) |
L6000xW1200xH1200 |
Max Length of Wood |
6m |
High Frequency |
6.78MHz |
Input Power |
40KVA |
Oscillation power |
30KW |
Vacuum pressure |
-0.093MPa |
Weight(kg) |
9000 |
Packing |
40HQ |
Kiln Temp |
Vacuum kiln Drying temperature: ≤90°C |
Moisture |
From 90% to 6% ,could be setting as per-request |
Drying time |
2-7 days |
Application |
Apply for all hardwood species |
what wood is suitable for plank drying kiln equipment?
==It is suitable for all kinds of wood, from /rosewood/veneer/lamina/board to thick lumber, even heavy timber with large dimension.
==For thin piece like veneer or floor board lamina, high frequency vacuum wood drying not only offer short drying cycle but also eliminate the problem of curve or shrink. For thick and hard wood, like Merbau, Mahogany, etc. HF wood dryer brings good drying quality with uniform moisture content, free of split or spark both on surface or inside of wood, short drying time will meet the customer's demand for production.
Charactor of lumber kiln drying vacuum design
A.OFFER ONE BUTTON CONTROL TECHNOLOGY
Full automatic drying program within PLC control system for different type of wood, the worker don’t need to know too much knowledge about wood drying cook th wood perfect.
B.PRECISE AND RELIABLE MONITORING SYSTEM
High precision and stable monitoring spare will always guide on the machine both for warrantee of good drying quality or safety of personal and machine.
C.WELL SELECT SPARE PARTS
We choose high grade stable spare parts which is tested for long time for the machine to make it stable running and problem free.
D.LOGICAL AND SAFE DESIGN
With more than 200 years of experienced engineer, the customer can expect a more logical and humanistic machine that very easy to use, stable running and help a lot in production.
Working principle diagram of plank drying kiln equipment
Using high frequency electric field is used as a heating source, even electric field radiation in the wood, and penetrates the wood directly on the water for heating, and the vacuum water absorption to accelerate water discharge.
Packing & shipment
1.Plastic and foam packing, fixed by wood pallet, it is packed in 40 feet high container.
2.by sea transport
Henan dingli drying equipment co.,ltd
1.We are Henan Dingli Drying Equipment Co.,Ltd, locate at No.59,Dongda Street, Guancheng Dist., Zhengzhou, China. we are professional manufacturer in new energy and biomass fuel ewuipment and have been 20 years experience.
2.our main equipment is drying machine, which devided into rotary dryer and HF wood vacuum dryer machine.
3.we are able to design suitable for your machine with your demands! welcome to visit our factory!
The mentioned above just our vacuum high efficient plank/wood chips drying kiln equipment, if you want to know more details, welcome to contact me!
