Plastic housing constant Voltage 12V 100w 8.3a led driver Waterproof LED power supply ip67 with input 100-240VAC led transformer
Features(STV-12-100): | ||
Constant voltage mode power supply | ||
Universal AC input | ||
Fully encapsulated with IP67 level | ||
Cooling: By Convection | ||
Class II power unit with fully isolated plastic case | ||
Protections: Short Circuit/Over Load/ Over Voltage/Thermal protection | ||
Small and compact size | ||
100% full load burn-in test | ||
Suitable for LED lighting and moving sign applications | ||
Two years warranty | ||
Specifications: | ||
Input |
Voltage |
100-240VAC |
Frequency |
47 to 63 Hz |
|
Efficiency |
83% |
|
Ac current |
0.85A/220VAC |
|
Inrush current |
Cold start 30A/240VAC |
|
Leakage current |
0.25mA/240VAC |
|
Output |
DC Voltage |
12V |
Rated Current |
8.5A |
|
Current Range |
0-8.5A |
|
Rated Power |
100W |
|
Ripple & noise (Max.) |
120mVp-p |
|
Environment |
Storage temperature |
-40-80 degree |
Operating temperature |
-30-50 degree |
|
Humidity operating |
20%-90% |
|
Humidity storage |
10%-95% |
|
Protections |
Short Circuit |
Auto recovery |
Over-load |
110-150%output rated power, recovers auto |
|
Over-voltage |
13.8-16.2V, recovers auto |
|
Thermal Protection |
≤85 degree |
|
CE |
CE Safety Standard |
Compliance to EN61347-1:2008&EN 61347-2-13:2006 |
EMI conduction & radiation |
Compliance to EN 55015: 2006+A1: 2007 EN 61547: 2004 |
|
Harmonic Current |
Compliance to EN 61000-3-2: 2006 EN 61000-3-3: 1995+A1: 2001+A2: 2005 |
|
Others |
Dimension/Weight |
189*52*37mm/660g |
Cable |
30mm |
|
Withstand voltage |
3KVAC |
|
1. T/T West Union, 30% deposit after order confirmed, the balance before shipment.
2. Lead time: normally in 5-7 workdays after deposit received.
3. Sample policy: Samples are always available for each model. Deliver Immediately once payment received.
4. Shipping port: Shenzhen, China.
5. Discounts: We offer discount for big quantity.
1. For all your inquiries about us or our products, we will reply you in detail within 24 hours.
2. Well-trained and professional sales & after- sale services stuff who can speak fluent English.
3. OEM service is available. Can print your own logo on product, customized the retail box packing.
4. With experienced R&D engineers and strong ability to do ODM projects.
