Help CenterGas Filter/ Coalesence Element/coalescence Separation Filter
Related Products
-
Replacement Hydac Filter 1320D005BN4HC OEM ServeUS$ 10 - 150MOQ: 2 Pieces -
Stainless Steel Suction Oil Filter ElementUS$ 15 - 100MOQ: 5 Pieces
-
Stainless Steel Oil Suction Line Filter ElementUS$ 15 - 100MOQ: 5 Pieces
-
Customize Stainless Steel Oil Suction Strainer ElementUS$ 15 - 100MOQ: 5 Pieces
-
Customize Hydraulic Oil Suction Line Filter ElementUS$ 15 - 100MOQ: 5 Pieces
Specifications
hydraulic oil filter element1-200 micron retention rates
cellulose, micron-glass and stainless steel wire mesh media
Oil filter impurities , moisture coalescing dual function is an important function of fine filter element . Coalescing filter can meet a variety of fine filters used in fixed mobile refueling facility needs.
Features:
1 , multi-layered composite structure with filter paper , filter and high precision :
2 , dirt holding capacity, long service life ;
3 , traffic density, reducing the fine filter size ;
4 , carefully set and specially treated glass fiber layer , good coalescence effect ;
5 , the structure and materials comply with the standard requirements ;
6, the full range of specifications to meet the needs of a variety of fine filter .
Coalescer primarily for liquid - liquid separation design , it contains two kinds of filter, namely: polypropylene filter and the separation filter. For example, in oil
Addition to the product water system , the oil flows into the coalescer , first passes through the coalescence filter , coalescing filter to filter solids , and
Tiny water droplets coalesce into larger drops . After most of the water droplets coalesce by gravity from the oil can be separated and removed , settling into
Sump . Then it flows through the oil separator filter , because the separation filter has good lipophilic hydrophobic , thus further points
Water from the final , clean, dry oil outflow coalescer . First by the lower portion of the inlet pipe into the oil filter housing
Then flows from the outside through the filter, then coarser particles will immediately settle down , release the drain valve , the smaller particles
Was blocked filter. After the last filter clean oil collection tray , the outflow from the outlet pipe of the coalescer , the oil to be treated with
Increase the amount of contaminants deposited on the filter causes a pressure rise in the coalescer . When the pressure rises to 0.15Mpa , the said
Ming coalescing filter is clogged and should be replaced. Coalescing oil separator from the inlet flow into a tray , and then split in a
Inside the filter , filtered , emulsion breaking, water molecules grow , coalescence process , level of impurities trapped in the filter, the coalesced water
Pearl settling in the sedimentation tank , oil filter from the outside into the secondary , pooling in the second tray from coalescing separator outlet stream
Out . Two filter material having a hydrophobic , oil can be passed , free water filters were blocked in addition , the inflow precipitation
Tank , sewage through discharge valve.
