Specifications
1.Donaldson filter elements2.steam and gas filter elements
3.Factory with OEM service
4.Fast Delivery
Donaldson steam and gas filter elements
The (P)-GS N filter consists of a regenerable pleated stainless steel filter matrix
in a stainless steel cartridge. The retention rate extends from 1 μm to 25 μm
Specification
Filtration surface
0,22 M2 per 250 mm element (10/30)
Filter Materials
Filter Matrix: Stainless Steel 1.4404
Support: Stainless Steel 1.4404
End Caps: Stainless Steel 1.4301
O-Rings: EPDM
Alternatively:Silicone Buna EPR PTFE over silicone PTFE over viton
Temperature Range
-50°C (-60°F) to 200°C (400°F)
> 150°C (300°F) welded end caps required
Maximum Differential Pressure
(Flow Direction: Outside to Inside)
5 bar (75 psid), independent of the system pressure or temperature
Features and Benefit
High dirt holding capacity at low differential pressure and high flow rate
Regenerable by Back-flushing or ultrasonication
Excellent material resistance towards Steam and aggressive media
Down to 0,01 µm in saturated steam
Dimensions
|
|
|
|
Retention Rate
|
We have our own factory! We have professional technology team! Welcom OEM. Many kinds of stainless steel filter elements could be manufactured according to customer's specification.
|
|
