Specifications
1.Coalescing filter cartridge2.Long service life
3.separate liquids that have low interfacial tension
4.ISO Test
1) Description
Pall’s PhaseSep®FR1 Series liquid / liquid coalescing filter cartridge is designed to directly retrofit Facet International coalescer vessels designed to hold tie-rod mount style liquid / liquid coalescers. The Pall PhaseSep FR1 system is a multiple stage unit starting with preconditioning of the fluid with a Pall particulate filter followed by the PhaseSep FR1 coalescer. The preconditioning filter removes particulate matter to prolong the service life of the PhaseSep FR1 coalescer and initiates coalescence of the dispersed phase.
2)Specification:
Dimensions
6 inch / 15.24 cm Nominal Diameter
20 inch / 50.8 cm Nominal Length
3)Materials of Construction
Item Materials
End Caps / Support Cage 316 Stainless Steel
Support / Drainage Layers 316L Stainless Steel
Medium Fluoropolymer Construction
Gasket Viton A**
4)Operating Characteristics
Maximum Temperature*:300°F / 149°C
Initial Pressure Drop:2 psid / 137 m bar d
Recommended Maximum Pressure Drop:15 psid / 1 bar d
5)Feature
Wide chemical and temperature compatibility
Can separate liquids that have low interfacial tension
Coalescence performance not impaired by the presence of surfactants or corrosion inhibitors
Long service life
No need to purchase new capital equipment
6)Benefit
Better to withstand upsets in pH and temperature
Eliminates need for emulsion breaking chemicals
Excellent fluid quality
Continuous protection of downstream equipment
Lower separation costs
Improved liquid/liquid separations with no capital expenditures
