High Speed Laminating Machine With Good Quality

Name: High Speed Laminating Machine With Good Quality
Brand: Ruigao
SKU: 121688561

US$ 10,000 - 300,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

Ruigao

Ruian Ruigao Machinery Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Zhejiang, China

Brand Name Ruigao

Model Number GF-A600

Voltage 380V

Power(W) 40kw

Dimension(L*W*H) 8.5*1.7*2.7

Weight 3000kg

Certification CE

Warranty One year guarantee

After-sales Service Provided Engineers available to service machinery overseas

Specifications

laminating machine
for film, paper, alum foil, BOPP materials laminating.
Economic Stable
High speed
has CE

High Speed Laminating Machine with Good Price

1. Machine Introduction

This machine is suitable for laminating plastic-plastic, paper-plastic, paper-paper and aluminum foils

and other laminated materials in the packing industry.

2. Machine Advantages

1, We use stronger steel plate for machine body, which makes machine more stable.

2, Motor with CE standard, more than 10 years life

3, Long Oven for drying the glue.

4, EPC for unwinder, and automatic tension controlling system for unwinder.

5, Anilox roller is 180 DPI.

3. Machine Parameters

Model	GF600A	GF800A	GF1000A	GF1200A
Material max width	600mm	8800mm	1000m	1200mm
Max unwinding diameter of material	650mm	650mm	650mm	650mm
Max rewinding diameter of material	650mm	650mm	650mm	650mm
Mechanical speed	90m/min	90m/min	90m/min	90m/min
Max laminating speed	80m/min	80m/min	80m/min	80m/min
Voltage	32kw	34kw	36kw	40kw
Machine weight	3000kg	3500kg	4000kg	5000kg
Outline dimension	8500/1330/2600 mm	8500/1530/2600 mm	8500/1730/2600 mm	8500/1930/2600 mm
