Help CenterFactory Price Optical Glass Prism Roof Prism
Related Products
-
Optical PrismUS$ 1 - 1MOQ: 1 Box -
Bk7 Optical Glass Educational PrismUS$ 1 - 10MOQ: 10 Pieces
-
China Supplier Equilateral 60 Degree Acrylic PrismUS$ 1 - 10MOQ: 10 Pieces
-
Factory Price Optical Lens Glass Prism Penta PrismUS$ 1 - 10MOQ: 10 Pieces
-
BK7 Optical Right Angle PrismUS$ 1 - 1MOQ: 1 Piece
1> ofession team: We have an excellent team, continue to provide qualit yservices.
2> Globle market: Our products are applied in many fields, is curently sold in Sotheast Asia, North Amercia, Europe and other regions and countries.
3> OEM/ ODM: We can according to the different needs with customized services.
4> Service Department: We have a complete after-sales service system, to help you from your worries.
Roof Prism
Roof Prism with high dimension control and apply to any Anti-reflecting coating.
It may be used to revert and invert the image as well as bend the line of sight through a 90 degree angle.
Specification:
Material |
BK7 grade A optical glass |
Dimension Tolerance |
+0.0, -0.2 mm |
Clear Aperture |
>85% |
Surface Quality |
60-40 scratch and dig |
Roof Angle Tolerance |
< 1 arc minute |
Flatness |
λ/2 @ 632.8 nm |
Protective Bevel |
0.25 mm x 45° |
BK7 Roof Prism Standard Products:
Part No. |
A (mm) |
B (mm) |
h (mm) |
TRP101 |
15.0 |
15.0 |
12.0 |
TRP102 |
23.0 |
23.0 |
18.0 |
TRP103 |
31.5 |
31.5 |
23.0 |
Note: Other size, material and coatings are available upon request.
Appllication:
♦ Television camera tube
♦ Thermal Image
♦ Medical Measurement
More Optical Prism:
Tian Cheng Optics Co., Ltd. is located in Changchun city where is famous base of optics research and development in China, we dedicate to designing and manufacturing high quality precision optical components including Lenses, High Precision Prism, Filter, Window, Beamsplitter, Mirror, Waveplate, Polarizer, Polarization Beamsplitter, Micro optics, they are widely used in industrial application, medical industry, construction, telecommunications, military, environment monitoring, life sciences, public security, aerospace etc. We have built well cooperation with some companies from United Kingdom,Germany, Ireland, Sweden, Australia, Brazil, U.S.A. etc.
1> Package Detail: A. Standard carbon and envelop with plastic foam.
B. Safety green carton.
C. Customized.
2> Delivery Detail: Within 20 days.(Also depand on the quantity)
1> Q: Where is your factory located ? How can I visit there ?
A: Our factory is located in Chaoyang district Changchun city Jilin province China, about 3 hours bus ride from Shanghai. All our clients, from home or abroad, are warmly welcome to visit us !
2> Q: What's the material of your products ?
A: The material is optical glass and plastic .
3> Q: If I place an order now, how long would it be before I got delivery ?
A: It would largely depend on the size of the order and the items you want .
4> Q: How can I get some samples ?
A: We are honored to offer you free samples.
