Specifications
Photocell control, photocell sensor for street lightingIP54 protection
13 years lifespan
Electronic time delay
Features and Benefits
· Meet stringent utility standards for street& highway lighting.
· Delayed response prevents switching due to light from vehicles, lightning, etc.
· Longer life extends the maintenance cycle for photocontrols mounted in difficult locations.
· Positive electronic switching provides quick made/break of the load relay eliminating relay chatter
· Regulated voltage and silicon photocell maintain accurate turn on /off points of the life of the control
· Low power consumption through a unique regulator circuit. Resulting low internal temperature rise contributes to long life.l For safety reasons, the RYG photocontrols are designed to fail in the ON position Features and Benefits
Applications
· Street way Lighting
· Building Perimeter Lighting
· Outdoor Advertising Signs
· Parking Lot Lighting
Specifications | |
· Nominal Voltages |
AC110-277/480V, 50/60 Hz. |
· Voltage Range |
Nominal Voltage ± 15% |
· Maximum Load |
1000 watt tungsten, 1800 VA. HID |
· Lifespan |
5000 operations minimum (13.7 years) |
· Turn-On/Turn-Off |
<1:5(Thermal ) |
· Delay Time(Instant on) |
Within 300 seconds |
· Operating temperature |
-40°C to +70°C(-40F to +158F) |
· Surge protection (MOV) |
90J, 180J, 320J (optional.) |
· Protection grade |
IP54 |
· Dielectric strength |
5000 volts between current carrying parts and metal surfaces |
· Average Power consumption |
<1 watts |
· Photocell |
Cadmium sulphide (Cds) |
· Materials |
Cover: Polypropylene UV stabilized, High impact, flammability resistance |
· Full warranty against defects in material and workmanship for 1 year from date of delivery. | |
