DIN3060 Ungalvanized 6x37FC Steel Wire Rope

Name: DIN3060 Ungalvanized 6x37FC Steel Wire Rope
Brand: Dawson
SKU: 121715219

US$ 0.6 - 1.1 MOQ: 1 Meter

Key Specifications

Steel Grade:

Steel

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Wire Gauge:

3-80mm

Qingdao Dawson Lifting & Rigging Industries Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QIngdao/Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Steel Grade Steel

Standard AISI, ASTM, BS, DIN, GB, JIS

Wire Gauge 3-80mm

Place of Origin Shandong, China

Type Other, Steel wire rope

Application Construction

Alloy Or Not Non-alloy

Model Number DS-WR-12

Brand Name Dawson

Product Description

DIN3060 Ungalvanized 6x37FC Steel Wire Rope

Steel Wire Ropes
Material	Steel
Sizes	3mm-80mm
Surface Finish	Galvanized and Ungalvanized
Core	IWRC, FC and WSC
Type	DIN,GB,BS,JIS,ASTM,AISI
Origin	China
Typical Wire Constructions	6x37, 6X19, 18x7 and more
Delivery Time	20days
Packaging	plastic spool, wood reel, coils, bag

Some Construction,Choose you want.

Construction	application
6×7 6×9W	Cable car, belt conveyer, cable way drawing and slope well winching
6×12 6×15	Tugboat, goods net, haulage, binding
6×19	Lifting machine, fishery, heat-moving machine and general machine
6×24 6×24S 6×24W	tugboat, fishery, cargo net, floating woods, binding, loading
6×37	Crane, hoist, loading, refloatation, fishery, vertical well balance
6×25Fi 6×29Fi 6×31SW 6×36SW	Lifting, hoisting and dragging. The rope with steel core may be used under the shock load, heated and squeezed condition.
6×7+NF 6×7+IWS 6×19+NF 6×19+IWS	For important machinery and instrument
6×19S+FC	For elevator


Left-hand ordinary lay (LHOL) wire rope (close-up). Right-hand lay strands are laid into a left-hand lay rope.	Right-hand Lang's lay (RHLL) wire rope (close-up). Right-hand lay strands are laid into a right-hand lay rope.

Picture Wire Rope
