624S+7FC ,624W+7FC Steel Wire Rope

Name: 6*24S+7FC ,6*24W+7FC Steel Wire Rope
Brand: Dawson
SKU: 121715293

US$ 0.6 - 1.1 MOQ: 1 Meter

Key Specifications

Steel Grade:

Steel

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Wire Gauge:

10mm-44mm

Qingdao Dawson Lifting & Rigging Industries Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QIngdao/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Steel Grade Steel

Standard AISI, ASTM, BS, DIN, GB, JIS

Wire Gauge 10mm-44mm

Place of Origin Shandong, China

Type Other, Steel wire rope

Application Construction

Alloy Or Not Non-alloy

Model Number DS-WR-031

Brand Name Dawson

Specifications

6*24S+7FC ,6*24W+7FC Steel Wire Rope
Sizes:10mm-44mm
Surface : Galvanized/Ungalvanized
Core : IWRC, FC and WSC

6*24S+7FC ,6*24W+7FC Steel Wire Rope

Steel Wire Ropes
Material	Steel
Sizes	8mm-40mm
Surface Finish	Galvanized and Ungalvanized
Core	IWRC, FC and WSC
Type	DIN,GB,BS,JIS,ASTM,AISI
Origin	China
OEM	Acceptable
Delivery Time	20days
Packaging	wooden reel , coils, plastic spool, bag and so on

Construction: 35W*7

Nominal Diameter		Approximate Weight	Nominal Tensile Strength of Rope(MPa)
			1470	1570	1670	1770	1870	1960
d	Allowed Tolerance		Minimum Breaking Load of Rope
mm	%	kg/100m	kN
10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44	+7 0	46.00 66.20 90.20 118.00 149.00 184.00 223.00 265.00 311.00 361.00 414.00 471.00 532.00 596.00 664.00 736.00 811.00 891.00	52.90 76.20 104.00 135.00 171.00 212.00 256.00 305.00 358.00 415.00 476.00 542.00 672.00 686.00 764.00 847.00 934.00 1020.00	56.50 81.40 111.00 145.00 183.00 226.00 274.00 326.00 382.00 443.00 509.00 579.00 653.00 732.00 816.00 904.00 997.00 1090.00	60.10 86.60 118.00 154.00 195.00 240.00 291.00 346.00 406.00 477.00 541.00 616.00 695.00 779.00 868.00 96200 1060.00 1160.00	63.70 91.80 125.00 163.00 206.00 255.00 308.00 367.00 431.00 500.00 573.00 652.00 737.00 826.00 920.00 1020.00 1120.00 1230.00	67.30 96.90 132.00 172.00 218.00 269.00 326.00 388.00 455.00 528.00 606.00 689.00 778.00 872.00 972.00 1080.00 1190.00 1300.00	70.60 102.00 138.00 181.00 229.00 282.00 342.00 406.00 477.00 553.00 635.00 723.00 816.00 914.00 1020.00 1130.00 1240.00 1370.00

Main Applications: Equipment for port load and unload derrick tower crane

Some Construction,Choose you want.

Construction	application
6×7 6×9W	Cable car, belt conveyer, cable way drawing and slope well winching
6×12 6×15	Tugboat, goods net, haulage, binding
6×19	Lifting machine, fishery, heat-moving machine and general machine
6×24 6×24S 6×24W	tugboat, fishery, cargo net, floating woods, binding, loading
6×37	Crane, hoist, loading, refloatation, fishery, vertical well balance
6×25Fi 6×29Fi 6×31SW 6×36SW	Lifting, hoisting and dragging. The rope with steel core may be used under the shock load, heated and squeezed condition.
6×7+NF 6×7+IWS 6×19+NF 6×19+IWS	For important machinery and instrument
6×19S+FC	For elevator


Left-hand ordinary lay (LHOL) wire rope (close-up). Right-hand lay strands are laid into a left-hand lay rope.	Right-hand Lang's lay (RHLL) wire rope (close-up). Right-hand lay strands are laid into a right-hand lay rope.

Picture Wire Rope

Packaging

Wire Rope Application

Certification

Wire Rope suoolier in china,any interest, contact us.Honest sevice will offer to you.
